Ref. No Part No. Description Remark Ref. No Part No. Description Remark
R1257 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1258 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1259 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1261 1-218-945-11 RES, CHIP 220 5% 1/16W
R1264 1-218-971-11 RES, CHIP 33K 5% 1/16W
R1265 1-218-971-11 RES, CHIP 33K 5% 1/16W
R1266 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1267 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1268 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1269 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1271 1-218-945-11 RES, CHIP 220 5% 1/16W
R1274 1-218-971-11 RES, CHIP 33K 5% 1/16W
R1275 1-218-971-11 RES, CHIP 33K 5% 1/16W
R1276 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1277 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1278 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1279 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1303 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1304 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1307 1-218-990-11 SHORT 0
R1308 1-218-990-11 SHORT 0
R1311 1-218-973-11 RES, CHIP 47K 5% 1/16W
R1312 1-218-973-11 RES, CHIP 47K 5% 1/16W
R1313 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1314 1-218-953-11 RES, CHIP 1K 5% 1/16W
R1315 1-218-285-11 RES, CHIP 75 5% 1/16W
R1321 1-216-150-91 RES, CHIP 10 5% 1/8W
R1323 1-218-965-11 RES, CHIP 10K 5% 1/16W
R1324 1-218-965-11 RES, CHIP 10K 5% 1/16W
R1325 1-218-990-11 SHORT 0
R1328 1-218-990-11 SHORT 0
R1329 1-218-990-11 SHORT 0
R1331 1-218-973-11 RES, CHIP 47K 5% 1/16W
R1332 1-216-033-91 RES, CHIP 220 5% 1/10W
< VARIABLE RESISTOR >
RV1301 1-241-748-11 RES, VAR, CARBON 10K/10K (VOL)
< SWITCH >
S1301 1-771-430-11 SWITCH, ROTARY ENCODER (BRIGHT)
< VIBRATOR >
X1001 1-579-738-21 VIBRATOR, CRYSTAL (14.318182MHz)
X1002 1-578-690-11 VIBRATOR, CERAMIC (500kHz)
X1003 1-579-466-11 VIBRATOR, CRYSTAL (3.579545MHz)
************************************************************
ACCESSORIES & PACKING MATERIALS
*****************************
0 1-475-822-23 ADAPTOR, AC (AC-PLM3)
0 *1-575-131-11 CORD, POWER
1-777-690-11 CORD, CONNECTION
0 1-790-107-22 CORD, POWER
3-050-106-01 HOOD (L)
X-3948-728-2 HOOD (R) ASSY, INTERCEPTION
X-3948-729-2 HOOD (L) ASSY, INTERCEPTION
