SECTION 7 ELECTRICAL PARTS LIST
A-8056-068-A DD-107 (H) COMPL
****************
3-050-086-01 CASE (UPPER), DD SHIELD
3-050-087-01 CASE (LOWER), DD SHIELD
4-640-703-01 SHEET, DD RADIATION
< CAPACITOR >
C701 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C702 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C703 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C704 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C705 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C706 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C707 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C708 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C709 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C710 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 16V
C711 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C712 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C713 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C714 1-164-936-11 CERAMIC CHIP 680PF 10% 16V
C715 1-164-936-11 CERAMIC CHIP 680PF 10% 16V
C716 1-164-936-11 CERAMIC CHIP 680PF 10% 16V
C717 1-164-936-11 CERAMIC CHIP 680PF 10% 16V
C718 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C719 1-117-370-11 CERAMIC CHIP 10uF 10V
C720 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C721 1-104-932-11 CERAMIC CHIP 10uF 16V
C722 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C723 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C725 1-119-751-11 TANTALUM CHIP 22uF 20% 16V
C726 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C727 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C728 1-117-370-11 CERAMIC CHIP 10uF 10V
C729 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C730 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C731 1-117-370-11 CERAMIC CHIP 10uF 10V
C732 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C751 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C752 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C753 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C754 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C755 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C756 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C757 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C758 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C759 1-113-642-11 TANTALUM CHIP 47uF 20% 10V
C760 1-115-581-11 TANTALUM CHIP 100uF 20% 16V
C761 1-164-852-11 CERAMIC CHIP 12PF 5% 16V
C762 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C763 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C764 1-164-872-11 CERAMIC CHIP 82PF 5% 16V
C765 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C766 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C767 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C769 1-104-823-11 TANTALUM CHIP 47uF 20% 16V
C770 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C781 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C782 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C783 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C784 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C785 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C786 1-104-932-11 CERAMIC CHIP 10uF 16V
C787 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C788 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
