7-2
Ref. No Part No. Description Remark Ref. No Part No. Description Remark
C789 1-113-981-11 TANTALUM CHIP 22uF 20% 20V
C790 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C791 1-117-370-11 CERAMIC CHIP 10uF 10V
C792 1-111-253-11 TANTALUM CHIP 100uF 20% 6.3V
< CONNECTOR >
CN701 1-750-358-21 CONNECTOR, FFC/FPC (ZIF) 30P
* CN702 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
CN703 1-770-623-21 PIN, CONNECTOR 6P
* CN704 1-695-320-21 PIN, CONNECTOR (1.5mm) (SMD) 2P
< DIODE >
D701 8-719-065-59 DIODE MBR0530T1
D702 8-719-065-59 DIODE MBR0530T1
D751 8-719-066-98 DIODE RB051L-40TE25
D752 8-719-066-98 DIODE RB051L-40TE25
D755 8-719-423-10 DIODE MA8100-M-TX
D781 8-719-420-90 DIODE MA8051-M-TX
D782 8-719-047-40 DIODE MA737-TX
D783 8-719-047-40 DIODE MA737-TX
D784 8-719-047-40 DIODE MA737-TX
D785 8-719-047-40 DIODE MA737-TX
D786 8-719-052-17 DIODE MA10705-TX
D787 8-719-017-76 DIODE MA8030-TX
D788 8-719-017-76 DIODE MA8030-TX
D789 8-719-420-90 DIODE MA8051-M-TX
D790 8-719-017-91 DIODE MA8160-TX
D791 8-719-017-91 DIODE MA8160-TX
D792 8-719-017-91 DIODE MA8160-TX
D793 8-719-017-91 DIODE MA8160-TX
D794 8-719-017-91 DIODE MA8160-TX
D795 8-719-017-91 DIODE MA8160-TX
D796 8-719-066-98 DIODE RB051L-40TE25
< FUSE >
0 F701 1-533-626-21 FUSE (SMD) (1.25A/125V)
0 F702 1-533-626-21 FUSE (SMD) (1.25A/125V)
0 F703 1-533-626-21 FUSE (SMD) (1.25A/125V)
0 F704 1-533-626-21 FUSE (SMD) (1.25A/125V)
0 F705 1-533-626-21 FUSE (SMD) (1.25A/125V)
0 F706 1-533-626-21 FUSE (SMD) (1.25A/125V)
< COIL >
FB781 1-469-176-21 INDUCTOR
FB782 1-469-176-21 INDUCTOR
< FILTER >
FL701 1-234-108-21 FILTER, EMI
FL702 1-234-108-21 FILTER, EMI
FL703 1-234-108-21 FILTER, EMI
FL704 1-234-108-21 FILTER, EMI
FL705 1-234-108-21 FILTER, EMI
FL706 1-234-108-21 FILTER, EMI
FL707 1-234-108-21 FILTER, EMI
FL708 1-234-108-21 FILTER, EMI
FL709 1-234-108-21 FILTER, EMI
< IC >
IC701 8-759-060-93 IC MB3785APFV-G-BND-ER
IC703 8-759-540-51 IC MAX863EEE-TG068
< JACK >
J701 1-568-727-31 JACK, DC (DC IN 8.4V)
< COIL >
L701 1-411-197-11 COIL, DD CONVERTER
L702 1-411-197-11 COIL, DD CONVERTER
L703 1-416-047-21 INDUCTOR 27uH
L704 1-416-047-21 INDUCTOR 27uH
L705 1-416-047-21 INDUCTOR 27uH
L706 1-414-757-11 INDUCTOR 100uH
L707 1-414-400-11 INDUCTOR 22uH
L708 1-414-756-11 INDUCTOR 47uH
L709 1-414-756-11 INDUCTOR 47uH
L710 1-469-021-21 INDUCTOR 4.7uH
L711 1-414-756-11 INDUCTOR 47uH
L712 1-469-021-21 INDUCTOR 4.7uH
L751 1-411-197-11 COIL, DD CONVERTER
L752 1-411-197-11 COIL, DD CONVERTER
L753 1-469-021-21 INDUCTOR 4.7uH
L754 1-469-021-21 INDUCTOR 4.7uH
L781 1-414-410-21 INDUCTOR 10uH
< FUSE >
0 PS701 1-533-979-21 FUSE (SMD) (500mA)
0 PS702 1-533-979-21 FUSE (SMD) (500mA)
< TRANSISTOR >
Q701 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q702 8-729-044-33 TRANSISTOR CPH6701-TL
Q703 8-729-044-33 TRANSISTOR CPH6701-TL
Q704 8-729-044-33 TRANSISTOR CPH6701-TL
Q705 8-729-045-31 TRANSISTOR MMDF3N04HDR2
Q706 8-729-928-90 TRANSISTOR DTC114EE-TL
Q707 8-729-928-27 TRANSISTOR DTA144EE-TL
Q751 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q753 8-729-928-81 TRANSISTOR DTC144EE-TL
Q781 8-729-928-81 TRANSISTOR DTC144EE-TL
Q782 8-729-928-81 TRANSISTOR DTC144EE-TL
Q783 8-729-928-81 TRANSISTOR DTC144EE-TL
Q784 8-729-928-81 TRANSISTOR DTC144EE-TL
Q785 8-729-928-81 TRANSISTOR DTC144EE-TL
Q786 8-729-928-81 TRANSISTOR DTC144EE-TL
Q787 8-729-928-81 TRANSISTOR DTC144EE-TL
Q788 8-729-928-81 TRANSISTOR DTC144EE-TL
Q789 8-729-928-81 TRANSISTOR DTC144EE-TL
Q791 8-729-041-69 TRANSISTOR MMSF5P02HDR2
Q792 8-729-041-69 TRANSISTOR MMSF5P02HDR2
Q793 8-729-041-69 TRANSISTOR MMSF5P02HDR2
Q794 8-729-041-69 TRANSISTOR MMSF5P02HDR2
DD-107 (H)
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
0印の部品，または0印付きの点線で囲まれた部品は，
安全性を維持するために重要な部品です。
従って交換時は，必ず指定の部品を使用して下さい。
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
