Ref. No Part No. Description Remark
Ref. No Part No. Description Remark
Q795 8-729-045- TRANSISTOR MMDF2P02HDR2
Q796 8-729-045- TRANSISTOR MMDF2P02HDR2
< RESISTOR >
R701 1-218-977-11 RES, CHIP 100K 5% 1/16W
R702 1-218-990-11 SHORT 0
R703 1-218-964-11 RES, CHIP 8.2K 5% 1/16W
R704 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
R705 1-218-873-11 METAL CHIP 12K 0.5% 1/16W
R706 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R707 1-218-971-11 RES, CHIP 33K 5% 1/16W
R708 1-218-970-11 RES, CHIP 27K 5% 1/16W
R709 1-218-962-11 RES, CHIP 5.6K 5% 1/16W
R710 1-218-963-11 RES, CHIP 6.8K 5% 1/16W
R711 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R712 1-218-877-11 METAL CHIP 18K 0.5% 1/16W
R713 1-218-885-11 METAL CHIP 39K 0.5% 1/16W
R714 1-218-974-11 RES, CHIP 56K 5% 1/16W
R716 1-218-969-11 RES, CHIP 22K 5% 1/16W
R717 1-218-862-11 METAL CHIP 4.3K 0.5% 1/16W
R718 1-218-973-11 RES, CHIP 47K 5% 1/16W
R719 1-218-964-11 RES, CHIP 8.2K 5% 1/16W
R720 1-218-873-11 METAL CHIP 12K 0.5% 1/16W
R721 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
R722 1-218-951-11 RES, CHIP 680 5% 1/16W
R723 1-218-873-11 METAL CHIP 12K 0.5% 1/16W
R724 1-218-881-11 METAL CHIP 27K 0.5% 1/16W
R725 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R726 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R727 1-220-254-11 RES, CHIP 56 5% 1/4W
R728 1-220-254-11 RES, CHIP 56 5% 1/4W
R729 1-216-033-91 RES, CHIP 220 5% 1/10W
R730 1-216-027-91 RES, CHIP 120 5% 1/10W
R731 1-218-990-11 SHORT 0
R735 1-218-990-11 SHORT 0
R738 1-218-990-11 SHORT 0
R751 1-218-919-91 METAL CHIP 1M 0.5% 1/16W
R752 1-218-865-11 METAL CHIP 5.6K 0.5% 1/16W
R753 1-218-893-11 METAL CHIP 82K 0.5% 1/16W
R754 1-218-919-91 METAL CHIP 1M 0.5% 1/16W
R755 1-218-884-11 METAL CHIP 36K 0.5% 1/16W
R756 1-218-901-11 METAL CHIP 180K 0.5% 1/16W
R757 1-218-977-11 RES, CHIP 100K 5% 1/16W
R758 1-218-973-11 RES, CHIP 47K 5% 1/16W
R759 1-218-973-11 RES, CHIP 47K 5% 1/16W
R760 1-218-942-11 RES, CHIP 120 5% 1/16W
R761 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R762 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R763 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R766 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R767 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R768 1-211-896-11 RES, CHIP 0.18 5% 1/10W
R769 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R770 1-218-973-11 RES, CHIP 47K 5% 1/16W
R780 1-216-200-11 RES, CHIP 1.2K 5% 1/8W
R781 1-218-873-11 METAL CHIP 12K 0.5% 1/16W
R782 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R783 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R784 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R785 1-216-200-11 RES, CHIP 1.2K 5% 1/8W
R786 1-218-973-11 RES, CHIP 47K 5% 1/16W
R787 1-218-973-11 RES, CHIP 47K 5% 1/16W
R788 1-218-973-11 RES, CHIP 47K 5% 1/16W
R789 1-218-973-11 RES, CHIP 47K 5% 1/16W
R790 1-218-973-11 RES, CHIP 47K 5% 1/16W
R791 1-218-973-11 RES, CHIP 47K 5% 1/16W
R792 1-218-973-11 RES, CHIP 47K 5% 1/16W
R793 1-218-973-11 RES, CHIP 47K 5% 1/16W
R794 1-216-057-91 RES, CHIP 2.2K 5% 1/10W
R795 1-216-057-91 RES, CHIP 2.2K 5% 1/10W
R796 1-218-867-11 METAL CHIP 6.8K 0.5% 1/16W
R797 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R798 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R799 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
< TRANSFORMER >
T701 1-431-942-21 TRANSFORMER, DC-DC CONVERTER
T702 1-431-980-21 TRANSFORMER
******************************************************************
A-8056-071-A JK-136 (H) MOUNT
****************
< CONNECTOR >
CN1401 1-779-884-11 CONNECTOR 4P
< DIODE >
D1401 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D1402 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D1403 8-719-422-86 DIODE MA8082-L-TX
< FERRITE BEAD >
FB1401 1-414-385-11 FERRITE BEAD 0uH
FB1402 1-414-385-11 FERRITE BEAD 0uH
FB1404 1-414-385-11 FERRITE BEAD 0uH
< JACK >
J1401 1-566-850-41 CONNECTOR, (S) TERMINAL 4P (S VIDEO)
< RESISTOR >
R1401 1-218-285-11 RES, CHIP 75 5% 1/16W
R1402 1-218-936-11 RES, CHIP 39 5% 1/16W
R1403 1-218-936-11 RES, CHIP 39 5% 1/16W
R1404 1-218-948-11 RES, CHIP 390 5% 1/16W
R1405 1-216-295-91 SHORT 0
******************************************************************
A-8056-053-A LC-61 (F) MOUNT
***************
< CAPACITOR >
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-113-985-11 TANTALUM CHIP 10uF 20% 20V
C803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C804 1-164-326-91 CERAMIC CHIP 0.47uF 16V
C805 1-164-326-91 CERAMIC CHIP 0.47uF 16V
