3-20
[Preset Data Writing]
Connection:
(1) Connect the adjusting remote commander to the CN501 on MA-324 (H) board, and set the [VIDEO] mode (S904).
Data Writing Procedure
(1) Set data: 01 to page: 0, address: 01.
(2) Enter the data given in the table below.
Note: To write the data to the EEPROM, press the PAUSE button on the adjusting remote commander each time the data is set.
(3) After writing all data, set data: 00 to page: 0, address: 01.
E and F Page Adjustment Address and Initial Value
Make setting and adjustment only when IC502 (EEPROM) was replaced.
E Page:
Address Data Remarks
00 01 Fixed value
01 EB
02 DC
Charge adj.
03 DA
04 8C
05 DE
06 4C
07 1D
08 08
09 07
0A 30 Fixed value
0B 75
0C 90
0D 7E
0E 40
0F ā FF ā Not used
Address Data Remarks
00 ā 0F ā Not used
10 40
11 01
12 0F
13 FF
14 00
15 07
16 FF
17 00
18 00
19 FF
1A FF
1B FF Fixed value
1C FF
1D FF
1E FF
1F FF
20 00
21 03
22 DE
23 86
24 12
25 1F
26 00
27 00
Address Data Remarks
28 01
29 03
2A 02
2B 05
2C 1D
2D FC
2E 1F
2F 18
30 04
31 40
32 10
33 06
34 47
35 03
36 00
37 00
38 00
39 24
3A 24
3B 24
3C 4C
3D 4C Fixed value
3E 4C
3F 3F
40 3F
41 3F
42 9C
43 9C
44 9C
45 00
46 00
47 00
48 40
49 40
4A 40
4B C1
4C C0
4D C0
4E 40
4F 00
50 40
51 3F
52 7A Video Mute Lvl adj.
53 3F Fixed value
Address Data Remarks
54 80 Fixed value
55 80 4 fsc FreeRun adj.
56 87 H-Sync adj.
57 80 Pw Sv Sensor adj.
58 00
59 00
5A 00
5B 00
5C 80
5D 80
5E 80
Fixed value
5F AE
60 AE
61 AE
62 03
63 03
64 03
65 2F
66 2F
67 2F
68 65 R Gain adj.
69 65 G Gain adj.
6A 65 B Gain adj.
6B 94 R Bias adj.
6C 94 G Bias adj.
6D 94 B Bias adj.
6E 80
6F 80
70 80
Fixed value
71 80
72 80
73 80
74 9A Signal Cen adj.
75 35 V COM R adj.
76 35 V COM L adj.
77 00 Fixed value
78 3E SID Lvl adj.
79 6A PRG Lvl adj.
7A 60 Blk Lim adj.
7B 1F
7C 00 Fixed value
7D FF
7E 5B
Battery down adj.
7F 63
