Sony MCS-8M - Page 70

KY-671 BOARD
Ref. No.
or Q'ty Part No. SP Description
S1154 1-771-721-21 s SWITCH, TACTILE
S1155 1-771-721-21 s SWITCH, TACTILE
S1156 1-771-721-21 s SWITCH, TACTILE
S1161 1-771-721-21 s SWITCH, TACTILE
S1162 1-771-721-21 s SWITCH, TACTILE
S1163 1-771-721-21 s SWITCH, TACTILE
S1164 1-771-721-21 s SWITCH, TACTILE
S1165 1-771-721-21 s SWITCH, TACTILE
S1166 1-771-721-21 s SWITCH, TACTILE
S1167 1-771-721-21 s SWITCH, TACTILE
S1168 1-771-721-21 s SWITCH, TACTILE
S1169 1-771-721-21 s SWITCH, TACTILE
S1170 1-771-721-21 s SWITCH, TACTILE
S1171 1-771-721-21 s SWITCH, TACTILE
S1172 1-771-721-21 s SWITCH, TACTILE
S1173 1-771-721-21 s SWITCH, TACTILE
S1174 1-771-721-21 s SWITCH, TACTILE
S1176 1-771-721-21 s SWITCH, TACTILE
S1181 1-771-721-21 s SWITCH, TACTILE
S1182 1-771-721-21 s SWITCH, TACTILE
S1183 1-771-721-21 s SWITCH, TACTILE
S1189 1-771-721-21 s SWITCH, TACTILE
S1190 1-771-721-21 s SWITCH, TACTILE
S1191 1-771-721-21 s SWITCH, TACTILE
S1192 1-771-721-21 s SWITCH, TACTILE
S1193 1-771-721-21 s SWITCH, TACTILE
S1194 1-771-721-21 s SWITCH, TACTILE
S1195 1-771-721-21 s SWITCH, TACTILE
S1196 1-771-721-21 s SWITCH, TACTILE
THP1 1-802-243-11 s THERMISTOR, POSITIVE
TP1 1-535-757-21 s CHIP, CHECKER
TP2 1-535-757-21 s CHIP, CHECKER
TP3 1-535-757-21 s CHIP, CHECKER
TP4 1-535-757-21 s CHIP, CHECKER
TP5 1-535-757-21 s CHIP, CHECKER
X1301 1-813-345-21 s VIBRATOR, CRYSTAL (30 MHz)
MIX-54 BOARD
Ref. No.
or Q'ty Part No. SP Description
1pc A-1813-112-A s MOUNTED CIRCUIT BOARD, MIX-54
1pc 1-528-174-72 s BATTERY, LITHIUM (CR2032 TYPE)
4pcs 3-364-941-12 s SCREW (+B) (2.6X5), NYLOK
0.8pcs 7-600-000-48 s ADHESIVE AGENT(SC608LVZ2)180ML
BT1 1-756-991-11 s HOLDER, LITHIUM BATTERY (CR203
C100 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C101 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C102 1-112-692-81 s CAP,CHIP CERAMIC1000PF CH 1005
C103 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C104 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C105 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C106 1-107-819-81 s CAP,CHIP CERAMIC 22000PF B1005
C107 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C108 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C109 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C110 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C111 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
MIX-54 BOARD
Ref. No.
or Q'ty Part No. SP Description
C112 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C113 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C200 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C201 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C202 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C203 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C204 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C205 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C206 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C207 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C208 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C209 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C210 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C211 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C212 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C213 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C214 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C215 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C216 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C217 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C218 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C219 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C220 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C221 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C222 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C223 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C224 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C225 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C226 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C227 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C228 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C229 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C230 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C231 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C300 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C301 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C302 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C303 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C304 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C305 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C306 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C307 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C308 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C309 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C310 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C311 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C312 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C313 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C314 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C315 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C316 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C317 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C318 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C319 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C320 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C321 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C322 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C323 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C401 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C402 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C403 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C404 1-112-815-91 s CAP, CERAMIC 10MF C (1608)
C600 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C601 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
C602 1-114-582-91 s CAP, CERAMIC 0.1MF B 1005
MCS-8M
2-22
