Sony MDS-JA20ES Service Manual

– 20 –
OVER WRITE HEAD
OPTICAL PICK-UP
3 over write head
2 screw
(P1.7 × 6)
1 flexible boar
d
(CN104)
2 screw
(B2
× 8)
3 leaf spring
(shaft)
4 main shaft
5 Remove the optical pick-up
in the arrow direction
A .
1 flexible board
(CN104)
1 flexible board
(CN101)
A
