Sony MDS-JA20ES Service Manual

– 72 –
6 IC100 0 (LRCK1)
7 IC100 !¡ (BCK1)
8 IC800 !¡ (XOUT)
9 IC800 !£ (XOUT)
– FL Board –
1 IC771 ^§ (OSCO)
2 IC771 ^∞ (OSCI)
3.6 Vp-p
22.7
µ s
3.5 Vp-p
354 ns
3.3 Vp-p
32 kHz
3.4 Vp-p
7 MHz
4 Vp-p
Approx. 2.5 MHz
1.8 Vp-p
Approx. 2.1 MHz
