– 90 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 151 4-999-519-01 BRACKET (TRAY)
* 152 4-987-267-01 TABLE (EJECT)
153 4-999-509-01 TRAY
154 4-999-528-01 RACK (L)
155 4-999-544-01 GEAR (TOP)
* 156 4-999-532-01 BRACKET (TOP)
157 4-999-535-01 SHAFT
158 4-987-271-01 STOPPER (SHAFT B)
159 X-4949-787-1 SLIDER (D) ASSY
160 4-999-512-01 GUIDE (SHAFT)
161 4-999-529-01 RACK (R)
* 162 1-669-050-11 OUT SWITCH BOARD
(4) MD MECHANISM SECTION-1
(MDM-6A)
#5
#5
#5
#5
#5
#5
#5
#5
#5
#4
156
157
158
160
155
155
159
154
153
152
151
162
not
supplied
not
supplied
161
