– 99 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R851 1-249-425-11 CARBON 4.7K 5% 1/4W
R852 1-249-393-11 CARBON 10 5% 1/4W
R853 1-249-426-11 CARBON 5.6K 5% 1/4W
< TRANSFORMER >
T300 1-416-701-11 COIL (WITH CORE)
************************************************************
* A-4724-137-A FL BOARD, COMPLETE (US, Canadian)
* A-4724-146-A FL BOARD, COMPLETE (AEP, UK)
******************
2-389-320-01 CUSHION
* 3-362-478-11 HOLDER (T), LED
* 4-996-686-11 HOLDER (FL)
< CAPACITOR >
C700 1-126-154-11 ELECT 47uF 20% 6.3V
C701 1-126-154-11 ELECT 47uF 20% 6.3V
C765 1-162-290-31 CERAMIC 470PF 10% 50V
C766 1-162-290-31 CERAMIC 470PF 10% 50V
C767 1-162-294-31 CERAMIC 0.001uF 10% 50V
C768 1-162-294-31 CERAMIC 0.001uF 10% 50V
C772 1-162-213-31 CERAMIC 39PF 5% 50V
C773 1-162-294-31 CERAMIC 0.001uF 10% 50V
C774 1-162-282-31 CERAMIC 100PF 10% 50V
C775 1-162-282-31 CERAMIC 100PF 10% 50V
C776 1-162-282-31 CERAMIC 100PF 10% 50V
C777 1-164-159-11 CERAMIC 0.1uF 50V
C778 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN701 1-784-337-11 CONNECTOR (FFC) 25P
CN751 1-784-642-11 CONNECTOR, BOARD TO BOARD 11P
< LED >
D753 8-719-303-02 LED SEL2510C-D (()
D754 8-719-301-52 LED SEL2810A-C (P)
D755 8-719-301-39 LED SEL2210S (r REC)
< FLUORESCENT INDICATOR TUBE >
FL781 1-517-738-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC771 8-759-525-49 IC MSM9201-02GS-K
< TRANSISTOR >
Q753 8-729-422-57 TRANSISTOR UN4111
Q754 8-729-422-57 TRANSISTOR UN4111
Q755 8-729-422-57 TRANSISTOR UN4111
Q781 8-729-620-05 TRANSISTOR 2SC2603-EF
Q782 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R702 1-249-421-11 CARBON 2.2K 5% 1/4W
R703 1-247-843-11 CARBON 3.3K 5% 1/4W
R704 1-249-425-11 CARBON 4.7K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-435-11 CARBON 33K 5% 1/4W
R712 1-249-421-11 CARBON 2.2K 5% 1/4W
R713 1-247-843-11 CARBON 3.3K 5% 1/4W
R714 1-249-425-11 CARBON 4.7K 5% 1/4W
R717 1-249-429-11 CARBON 10K 5% 1/4W
R718 1-249-435-11 CARBON 33K 5% 1/4W
R753 1-247-807-31 CARBON 100 5% 1/4W
R754 1-249-406-11 CARBON 120 5% 1/4W
R755 1-249-409-11 CARBON 220 5% 1/4W
R772 1-247-843-11 CARBON 3.3K 5% 1/4W
R773 1-247-807-31 CARBON 100 5% 1/4W
R774 1-247-807-31 CARBON 100 5% 1/4W
R775 1-247-807-31 CARBON 100 5% 1/4W
R776 1-247-807-31 CARBON 100 5% 1/4W
R781 1-247-807-31 CARBON 100 5% 1/4W
R782 1-249-441-11 CARBON 100K 5% 1/4W
R783 1-247-807-31 CARBON 100 5% 1/4W
R784 1-249-441-11 CARBON 100K 5% 1/4W
R785 1-247-807-31 CARBON 100 5% 1/4W
R786 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (r REC)
S702 1-762-875-21 SWITCH, KEYBOARD (p)
S703 1-762-875-21 SWITCH, KEYBOARD ())
S704 1-762-875-21 SWITCH, KEYBOARD (0)
S705 1-762-875-21 SWITCH, KEYBOARD (P)
S706 1-762-875-21 SWITCH, KEYBOARD (()
S711 1-762-875-21 SWITCH, KEYBOARD (MENU/NO)
S712 1-762-875-21 SWITCH, KEYBOARD (YES)
S713 1-475-543-11 ENCODER, ROTARY
(≠ AMS ±, PUSH ENTER)
S714 1-762-875-21 SWITCH, KEYBOARD (CLEAR)
S716 1-762-875-21 SWITCH, KEYBOARD (§ OPEN/CLOSE)
S740 1-475-766-11 ENCODER, ROTARY (DIGITAL REC LEVEL)
************************************************************
* 1-669-292-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C793 1-126-009-81 ELECT 100uF 20% 16V
C794 1-124-473-11 ELECT 1000uF 20% 10V
C795 1-162-290-31 CERAMIC 470PF 10% 50V
C796 1-162-290-31 CERAMIC 470PF 10% 50V
C797 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN790 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< IC >
IC790 8-759-634-50 IC M5218AL
< JACK >
J790 1-770-904-11 JACK (LARGE TYPE)(PHONES)
DIGITAL FL HEADPHONE
To Next Page
