Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
! R778 1-247-731-11 CARBON 22 5% 1/2W F
! R779 1-247-727-11 CARBON 10 5% 1/2W F
R790 1-247-807-31 CARBON 100 5% 1/4W
R791 1-249-433-11 CARBON 22K 5% 1/4W
R792 1-249-441-11 CARBON 100K 5% 1/4W
R793 1-249-429-11 CARBON 10K 5% 1/4W
R794 1-249-433-11 CARBON 22K 5% 1/4W
R795 1-247-807-31 CARBON 100 5% 1/4W
R796 1-249-433-11 CARBON 22K 5% 1/4W
R797 1-249-441-11 CARBON 100K 5% 1/4W
R798 1-249-429-11 CARBON 10K 5% 1/4W
R799 1-249-433-11 CARBON 22K 5% 1/4W
< VARIABLE RESISTOR >
RV790 1-225-645-11 RES, VAR 20K/20K (PHONE LEVEL)
************************************************************
* 1-669-049-11 MOTOR BOARD
*************
<CAPACITOR>
C10 1-164-159-11 CERAMIC 0.1uF 50V
<CONNECTOR>
CN14 1-506-481-11 PIN, CONNECTOR 2P
************************************************************
* 1-669-050-11 OUT SWITCH BOARD
*****************
<CONNECTOR>
* CN10 1-568-951-11 PIN, CONNECTOR 2P
<SWITCH>
S10 1-571-300-21 SWITCH, ROTARY (TRAY OPEN)
************************************************************
* 1-669-051-11 POSITION SWITCH BOARD
**********************
<CONNECTOR>
CN12 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
<SWITCH>
S11 1-771-264-11 SWITCH, PUSH (CHUCKING IN)
S12 1-771-264-11 SWITCH, PUSH (REC POSITION)
S13 1-771-264-11 SWITCH, PUSH (PLAY POSITION)
************************************************************
* A-4724-134-A POWER BOARD, COMPLETE (US, Canadian)
* A-4724-143-A POWER BOARD, COMPLETE (AEP, UK)
***********************
* 3-309-144-21 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C400 1-162-306-11 CERAMIC 0.01uF 20% 16V
C401 1-162-306-11 CERAMIC 0.01uF 20% 16V
C402 1-126-933-11 ELECT 100uF 20% 16V
C403 1-164-159-11 CERAMIC 0.1uF 50V
C404 1-126-965-11 ELECT 22uF 20% 50V
C700 1-126-916-11 ELECT 1000uF 20% 6.3V
C701 1-126-925-11 ELECT 470uF 20% 10V
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C704 1-126-916-11 ELECT 1000uF 20% 6.3V
C705 1-164-159-11 CERAMIC 0.1uF 50V
C706 1-126-939-11 ELECT 10000uF 20% 16V
C707 1-126-963-11 ELECT 4.7uF 20% 50V
C708 1-126-966-11 ELECT 33uF 20% 50V
C709 1-126-939-11 ELECT 10000uF 20% 16V
C710 1-126-969-11 ELECT 220uF 20% 50V
C711 1-164-159-11 CERAMIC 0.1uF 50V
C712 1-128-554-11 ELECT 330uF 20% 63V
C713 1-164-159-11 CERAMIC 0.1uF 50V
C714 1-164-159-11 CERAMIC 0.1uF 50V
C715 1-164-159-11 CERAMIC 0.1uF 50V
C716 1-164-159-11 CERAMIC 0.1uF 50V
C717 1-164-159-11 CERAMIC 0.1uF 50V
C718 1-164-159-11 CERAMIC 0.1uF 50V
C719 1-164-159-11 CERAMIC 0.1uF 50V
C726 1-164-159-11 CERAMIC 0.1uF 50V
C727 1-164-159-11 CERAMIC 0.1uF 50V
C728 1-126-234-11 ELECT 2200uF 20% 16V
C729 1-126-234-11 ELECT 2200uF 20% 16V
C730 1-164-159-11 CERAMIC 0.1uF 50V
C731 1-164-159-11 CERAMIC 0.1uF 50V
C732 1-117-771-11 ELECT(BLOCK) 6800uF 20% 25V
C733 1-117-771-11 ELECT(BLOCK) 6800uF 20% 25V
C734 1-164-159-11 CERAMIC 0.1uF 50V
C735 1-136-153-00 FILM 0.01uF 5% 50V
C736 1-136-153-00 FILM 0.01uF 5% 50V
C737 1-126-935-11 ELECT 470uF 20% 16V
C740 1-126-964-11 ELECT 10uF 20% 50V
C741 1-164-159-11 CERAMIC 0.1uF 50V
C742 1-164-159-11 CERAMIC 0.1uF 50V
C743 1-164-159-11 CERAMIC 0.1uF 50V
C744 1-164-159-11 CERAMIC 0.1uF 50V
C745 1-164-159-11 CERAMIC 0.1uF 50V
C746 1-164-159-11 CERAMIC 0.1uF 50V
C747 1-164-159-11 CERAMIC 0.1uF 50V
C748 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN401 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN700 1-564-513-11 PLUG, CONNECTOR 10P
CN701 1-770-655-11 CONNECTOR, FFC/FPC 27P
CN704 1-770-649-11 CONNECTOR, FFC/FPC 21P
< DIODE >
D400 8-719-933-39 DIODE HZS6C1L
D705 8-719-068-31 DIODE HZ7.5CP-TK
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
