– 101 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D706 8-719-200-77 DIODE 10E2N
D708 8-719-911-19 DIODE 1SS119
D709 8-719-911-19 DIODE 1SS119
D710 8-719-911-19 DIODE 1SS119
D711 8-719-200-77 DIODE 10E2N
D712 8-719-200-77 DIODE 10E2N
D713 8-719-210-21 DIODE 11EQS04
D714 8-719-210-21 DIODE 11EQS04
D715 8-719-911-55 DIODE U05G
D716 8-719-911-55 DIODE U05G
D717 8-719-911-55 DIODE U05G
D718 8-719-911-55 DIODE U05G
D719 8-719-200-77 DIODE 10E2N
D720 8-719-200-77 DIODE 10E2N
D721 8-719-911-19 DIODE 1SS119
< GROUND PLATE >
* EP700 4-870-539-00 PLATE, GROUND
< FUSE >
! F700 1-532-771-21 FUSE, MICRO (SECONDARY)(315mA/125V)
(US, Canadian)
< IC >
IC400 8-759-822-09 IC LB1641
IC700 8-759-525-48 IC LA5632
IC701 8-759-633-42 IC M5293L
IC702 8-759-604-90 IC M5F7907L
IC703 8-759-604-86 IC M5F7807L
IC704 8-759-513-71 IC PQ05RF21
< IC LINK >
! ICP700 1-532-834-21 LINK, IC (AEP, UK)
! ICP703 1-532-843-21 LINK, IC (AEP, UK)
! ICP704 1-532-843-21 LINK, IC (AEP, UK)
< TRANSISTOR >
Q400 8-729-900-80 TRANSISTOR DTC114ES
Q401 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q703 8-729-140-98 TRANSISTOR 2SD773-34
Q705 8-729-140-98 TRANSISTOR 2SD773-34
< RESISTOR >
R400 1-249-429-11 CARBON 10K 5% 1/4W
R401 1-249-429-11 CARBON 10K 5% 1/4W
R402 1-249-433-11 CARBON 22K 5% 1/4W
R403 1-249-417-11 CARBON 1K 5% 1/4W
R701 1-249-429-11 CARBON 10K 5% 1/4W
R703 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-412-11 CARBON 390 5% 1/4W
R707 1-249-433-11 CARBON 22K 5% 1/4W
R708 1-247-843-11 CARBON 3.3K 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-429-11 CARBON 10K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-437-11 CARBON 47K 5% 1/4W
R715 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY700 1-515-925-11 RELAY
************************************************************
* A-4724-138-A PSW BOARD, COMPLETE (US, Canadian)
* A-4724-147-A PSW BOARD, COMPLETE (AEP, UK)
*********************
< CAPACITOR >
C761 1-126-154-11 ELECT 47uF 20% 6.3V
C762 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN750 1-784-641-11 CONNECTOR, BOARD TO BOARD 11P
< LED >
D756 8-719-046-46 LED SEL5221S-TH8F (STANDBY)
D757 8-719-303-02 LED SEL2510C-D (FILTER)
D758 8-719-301-52 LED SEL2810A-C (MEGA CONTROL)
< IC >
IC761 8-749-013-92 IC GP1UC7X
< TRANSISTOR >
Q756 8-729-422-57 TRANSISTOR UN4111
Q757 8-729-422-57 TRANSISTOR UN4111
Q758 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R722 1-249-421-11 CARBON 2.2K 5% 1/4W
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W
R725 1-249-429-11 CARBON 10K 5% 1/4W
R726 1-249-435-11 CARBON 33K 5% 1/4W
R732 1-249-421-11 CARBON 2.2K 5% 1/4W
R733 1-247-843-11 CARBON 3.3K 5% 1/4W
R734 1-249-425-11 CARBON 4.7K 5% 1/4W
R742 1-249-426-11 CARBON 5.6K 5% 1/4W
R743 1-249-425-11 CARBON 4.7K 5% 1/4W
R744 1-249-429-11 CARBON 10K 5% 1/4W
R745 1-249-435-11 CARBON 33K 5% 1/4W
R751 1-249-429-11 CARBON 10K 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R756 1-249-409-11 CARBON 220 5% 1/4W
R757 1-249-406-11 CARBON 120 5% 1/4W
R758 1-249-409-11 CARBON 220 5% 1/4W
R761 1-249-401-11 CARBON 47 5% 1/4W
R762 1-247-807-31 CARBON 100 5% 1/4W
R787 1-247-807-31 CARBON 100 5% 1/4W
R788 1-247-807-31 CARBON 100 5% 1/4W
R789 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
POWER PSW
To Next Page
