Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S722 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S723 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S724 1-762-875-21 SWITCH, KEYBOARD (SCROLL/CLOCK SET)
S725 1-762-875-21 SWITCH, KEYBOARD (DISPLAY/CHAR)
S726 1-762-875-21 SWITCH, KEYBOARD (1/u)
S731 1-762-875-21 SWITCH, KEYBOARD (TIME)
S732 1-762-875-21 SWITCH, KEYBOARD (FADER)
S733 1-762-875-21 SWITCH, KEYBOARD (FILTER)
S734 1-762-875-21 SWITCH, KEYBOARD (MEGA CONTROL)
S741 1-771-171-11 SWITCH, ROTARY (INPUT)
S751 1-572-625-11 SWITCH, SLIDE (TIMER)
************************************************************
* 1-669-454-11 RELEASE BOARD
**************
< BATTERY >
BT701 1-528-739-11 BATTERY, LITHIUM (SECONDARY)
< CONNECTOR >
* CN703 1-569-499-11 PIN, CONNECTOR 3P
************************************************************
MISCELLANEOUS
***************
74 1-783-987-11 WIRE (FLAT TYPE) (25 CORE)
106 1-783-988-11 WIRE (FLAT TYPE) (23 CORE)
107 1-783-985-11 WIRE (FLAT TYPE) (27 CORE) (NOT BENDED)
108 1-783-989-11 WIRE (FLAT TYPE) (11 CORE)
! 111 1-558-568-21 CORD, POWER (AEP)
! 111 1-559-583-21 CORD, POWER (US, Canadian)
! 111 1-696-586-11 CORD, POWER (UK)
115 1-783-986-11 WIRE (FLAT TYPE) (27 CORE) (BENDED)
119 1-783-984-11 WIRE (FLAT TYPE) (21 CORE)
251 1-667-954-11 FLEXIBLE BOARD
! 259 8-583-028-02 OPTICAL PICK-UP KMS-260A/J1N
261 1-500-565-11 HEAD, OVER LIGHT
M101 A-4672-475-A MOTOR ASSY, SPINDLE
M102 A-4672-474-A MOTOR ASSY, SLED
M103 X-4949-791-1 MOTOR (LOADING) ASSY
S102 1-762-148-21 SWITCH, PUSH (2 KEY)
! T700 1-431-880-11 TRANSFORMER, POWER (AEP, UK)
! T700 1-431-881-11 TRANSFORMER, POWER (US, Canadian)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-885-09 SCREW +BVTT 4X16 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
#3 7-685-871-01 SCREW +BVTT 3X6 (S)
#4 7-685-103-19 SCREW +P 2X5 TYPE2 NON-SLIT
#5 7-685-133-19 SCREW (DIA. 2.6) (IT3B)
#6 7-621-772-00 SCREW +B 2X3
#7 7-621-772-20 SCREW +B 2X5
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Sony Corporation
Home A&V Products Company
9-922-875-11
98F0572-1
Printed in Japan © 1998. 6
Published by Quality Assurance Dept.
(Shibaura)
MDS-JA20ES
PSW RELEASE
#8 7-621-772-40 SCREW +B 2X8
#9 7-627-852-08 SCREW, PRECISION +P 1.7X2.5
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-475-775-11 REMOTE COMMANDER (RM-D19M)
1-590-925-31 CORD, CONNECTION (AUDIO PIN CABLE)
1-777-172-11 CORD, CONNECTION (CONTROL AI CABLE)
(Canadian)
3-862-517-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
3-862-517-21 MANUAL, INSTRUCTION
(GERMAN, SPANISH, ITALIAN ) (AEP)
3-862-517-31 MANUAL, INSTRUCTION
(DUTCH, SWEDISH, PORTUGUESE) (AEP)
4-983-537-01 COVER, BATTERY (for RM-D19M)
