Sony MDS-JA333ES Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
82
BD
R179 1-216-085-00 METAL CHIP 33K 5% 1/10W
R180 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-089-11 RES-CHIP 47K 5% 1/10W
R183 1-216-089-11 RES-CHIP 47K 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R185 1-216-081-00 METAL CHIP 22K 5% 1/10W
R186 1-216-089-11 RES-CHIP 47K 5% 1/10W
R188 1-216-073-00 METAL CHIP 10K 5% 1/10W
R189 1-216-073-00 METAL CHIP 10K 5% 1/10W
R190 1-216-073-00 METAL CHIP 10K 5% 1/10W
R195 1-216-073-00 METAL CHIP 10K 5% 1/10W
R196 1-216-295-11 SHORT 0
R197 1-216-295-11 SHORT 0
R198 1-216-296-91 SHORT 0
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1KEY)(LIMIT IN)
************************************************************
1-678-458-11 CONT-A1 BOARD
*************
< CAPACITOR >
C461 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C462 1-104-646-11 CERAMIC 2.2uF 20.00% 50V
C463 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C464 1-163-038-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN461 1-784-923-11 PIN, CONNECTOR 7P
< DIODE >
D461 8-719-988-61 DIODE 1SS355TE-17
< GROUND >
EP461 1-537-771-21 TERMINAL BOARD, GROUND
< JACK >
J461 1-779-655-21 JACK (SMALL TYPE)(2GANG)(CONTROL A1II)
< JUMPER RESISTOR >
JR801 1-216-296-91 SHORT 0
< TRANSISTOR >
Q461 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R461 1-216-073-00 METAL CHIP 10K 5% 1/10W
R462 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R463 1-216-001-00 METAL CHIP 10 5% 1/10W
R464 1-216-025-11 RES-CHIP 100 5% 1/10W
R465 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
************************************************************
A-4725-243-A DA BOARD, COMPLETE
******************
< BAR >
* BB501 1-560-242-31 BUS BAR 5P
< CAPACITOR >
C430 1-126-934-11 ELECT 220uF 20.00% 10V
C431 1-164-159-11 CERAMIC 0.1uF 50V
C432 1-164-159-11 CERAMIC 0.1uF 50V
C433 1-104-664-11 ELECT 47uF 20.00% 16V
C434 1-126-934-11 ELECT 220uF 20.00% 10V
C435 1-164-159-11 CERAMIC 0.1uF 50V
C436 1-164-159-11 CERAMIC 0.1uF 50V
C437 1-104-664-11 ELECT 47uF 20.00% 16V
C442 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-126-934-11 ELECT 220uF 20.00% 10V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-164-159-11 CERAMIC 0.1uF 50V
C504 1-124-995-11 ELECT 220uF 20.00% 10V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-124-995-11 ELECT 220uF 20.00% 10V
C507 1-164-159-11 CERAMIC 0.1uF 50V
C508 1-124-995-11 ELECT 220uF 20.00% 10V
C509 1-164-159-11 CERAMIC 0.1uF 50V
C510 1-124-995-11 ELECT 220uF 20.00% 10V
C511 1-164-159-11 CERAMIC 0.1uF 50V
C512 1-126-934-11 ELECT 220uF 20.00% 10V
C513 1-164-159-11 CERAMIC 0.1uF 50V
C514 1-126-934-11 ELECT 220uF 20.00% 10V
C515 1-164-159-11 CERAMIC 0.1uF 50V
C516 1-164-159-11 CERAMIC 0.1uF 50V
C517 1-164-159-11 CERAMIC 0.1uF 50V
C519 1-102-943-00 CERAMIC 6.0PF 50V
C520 1-102-943-00 CERAMIC 6.0PF 50V
C525 1-126-013-11 ELECT 1000uF 20.00% 16V
C526 1-126-049-11 ELECT 22uF 20.00% 25V
C527 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C528 1-126-049-11 ELECT 22uF 20.00% 25V
C529 1-164-159-11 CERAMIC 0.1uF 50V
C530 1-164-159-11 CERAMIC 0.1uF 50V
C531 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C532 1-164-159-11 CERAMIC 0.1uF 50V
C533 1-164-159-11 CERAMIC 0.1uF 50V
C535 1-164-159-11 CERAMIC 0.1uF 50V
C537 1-126-009-81 ELECT 100uF 20.00% 16V
C541 1-126-009-81 ELECT 100uF 20.00% 16V
C543 1-164-159-11 CERAMIC 0.1uF 50V
C544 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C545 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C547 1-126-022-11 ELECT 47uF 20.00% 25V
C548 1-126-022-11 ELECT 47uF 20.00% 25V
C549 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C550 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C551 1-126-009-81 ELECT 100uF 20.00% 16V
C553 1-126-009-81 ELECT 100uF 20.00% 16V
C556 1-130-973-00 FILM 0.022uF 5.00% 63V
CONT-A1 DA
