Sony MDS-JA333ES Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
83
DA
C557 1-130-973-00 FILM 0.022uF 5.00% 63V
C562 1-136-154-00 MYLAR 0.012uF 5.00% 50V
C563 1-136-154-00 MYLAR 0.012uF 5.00% 50V
C564 1-136-154-00 MYLAR 0.012uF 5.00% 50V
C565 1-136-154-00 MYLAR 0.012uF 5.00% 50V
C566 1-130-479-00 MYLAR 0.0047uF 5% 50V
C567 1-130-479-00 MYLAR 0.0047uF 5% 50V
C568 1-130-479-00 MYLAR 0.0047uF 5% 50V
C569 1-130-479-00 MYLAR 0.0047uF 5% 50V
C570 1-130-467-00 MYLAR 470PF 5% 50V
C571 1-130-467-00 MYLAR 470PF 5% 50V
C572 1-130-467-00 MYLAR 470PF 5% 50V
C573 1-130-467-00 MYLAR 470PF 5% 50V
C574 1-162-294-31 CERAMIC 0.001uF 10% 50V
C575 1-162-282-31 CERAMIC 100PF 10% 50V
C576 1-130-479-00 MYLAR 0.0047uF 5% 50V
C577 1-130-479-00 MYLAR 0.0047uF 5% 50V
C578 1-162-282-31 CERAMIC 100PF 10% 50V
C580 1-130-471-00 MYLAR 0.001uF 5% 50V
C581 1-130-471-00 MYLAR 0.001uF 5% 50V
C582 1-126-052-11 ELECT 100uF 20.00% 50V
C583 1-126-052-11 ELECT 100uF 20.00% 50V
C588 1-124-699-11 ELECT 220uF 20.00% 25V
C589 1-124-699-11 ELECT 220uF 20.00% 25V
C590 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-102-934-00 CERAMIC 1.0PF 50V
C603 1-162-211-31 CERAMIC 33PF 5% 50V
C605 1-164-159-11 CERAMIC 0.1uF 50V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-164-159-11 CERAMIC 0.1uF 50V
C608 1-164-159-11 CERAMIC 0.1uF 50V
C609 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-164-159-11 CERAMIC 0.1uF 50V
C611 1-164-159-11 CERAMIC 0.1uF 50V
C613 1-162-215-31 CERAMIC 47PF 5% 50V
C615 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN501 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF)) 21P
CN502 1-779-295-11 CONNECTOR,FFC(LIF(NON-ZIF)) 27P
CN503 1-793-565-11 CONNECTOR,FFC(LIF(NON-ZIF)) 13P
CN504 1-784-923-11 PIN, CONNECTOR 7P
CN505 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN506 1-784-922-11 PIN, CONNECTOR 5P
CN507 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
< DIODE >
D503 8-719-911-19 DIODE 1SS133T-72
D505 8-719-210-21 DIODE 11EQS04-TA2B
< TERMINAL >
ET501 4-924-264-01 TERMINAL, MOUNT
< IC >
IC501 8-759-678-29 IC CXD9556AQ
IC503 8-759-604-35 IC M5F78M05L
IC504 8-759-371-51 IC CXA8042AS
IC505 8-759-371-51 IC CXA8042AS
IC508 8-759-712-02 IC NJM2114D
IC509 8-759-712-02 IC NJM2114D
IC510 8-759-712-02 IC NJM2114D
IC511 8-759-712-02 IC NJM2114D
< COIL >
L501 1-408-599-31 INDUCTOR 4.7uH
L502 1-408-599-31 INDUCTOR 4.7uH
* L503 1-410-858-21 INDUCTOR 0uH
* L504 1-410-858-21 INDUCTOR 0uH
L505 1-408-599-31 INDUCTOR 4.7uH
L506 1-408-599-31 INDUCTOR 4.7uH
L507 1-408-599-31 INDUCTOR 4.7uH
L508 1-408-599-31 INDUCTOR 4.7uH
L509 1-408-599-31 INDUCTOR 4.7uH
* L518 1-410-858-21 INDUCTOR 0uH
* L519 1-410-858-21 INDUCTOR 0uH
< TRANSISTOR >
Q505 8-729-140-98 TRANSISTOR 2SD773-T-34
< RESISTOR >
R501 1-247-807-31 CARBON 100 5% 1/4W
R502 1-247-807-31 CARBON 100 5% 1/4W
R503 1-247-807-31 CARBON 100 5% 1/4W
R504 1-247-807-31 CARBON 100 5% 1/4W
R505 1-247-807-31 CARBON 100 5% 1/4W
R506 1-247-807-31 CARBON 100 5% 1/4W
R507 1-247-807-31 CARBON 100 5% 1/4W
R510 1-247-807-31 CARBON 100 5% 1/4W
R511 1-247-807-31 CARBON 100 5% 1/4W
R518 1-247-807-31 CARBON 100 5% 1/4W
R519 1-249-401-11 CARBON 47 5% 1/4W F
R520 1-249-425-11 CARBON 4.7K 5% 1/4W F
R521 1-259-404-11 CARBON 100 5% 1/6W
R522 1-259-404-11 CARBON 100 5% 1/6W
R523 1-259-404-11 CARBON 100 5% 1/6W
R524 1-259-404-11 CARBON 100 5% 1/6W
R525 1-259-404-11 CARBON 100 5% 1/6W
R526 1-259-404-11 CARBON 100 5% 1/6W
R527 1-259-404-11 CARBON 100 5% 1/6W
R528 1-259-404-11 CARBON 100 5% 1/6W
R529 1-259-416-11 CARBON 330 5% 1/6W
R530 1-259-416-11 CARBON 330 5% 1/6W
R531 1-249-504-11 CARBON 10 5% 1/4W
R532 1-249-504-11 CARBON 10 5% 1/4W
R533 1-249-504-11 CARBON 10 5% 1/4W
R534 1-249-504-11 CARBON 10 5% 1/4W
R535 1-249-504-11 CARBON 10 5% 1/4W
R536 1-249-504-11 CARBON 10 5% 1/4W
R537 1-249-504-11 CARBON 10 5% 1/4W
R538 1-249-504-11 CARBON 10 5% 1/4W
R539 1-249-885-11 CARBON 27 5% 1/4W
R540 1-249-885-11 CARBON 27 5% 1/4W
R541 1-249-885-11 CARBON 27 5% 1/4W
R542 1-249-885-11 CARBON 27 5% 1/4W
R543 1-249-542-11 CARBON 390 5% 1/4W
