Sony MDS-JA333ES Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
84
R544 1-249-542-11 CARBON 390 5% 1/4W
R545 1-249-542-11 CARBON 390 5% 1/4W
R546 1-249-542-11 CARBON 390 5% 1/4W
R547 1-249-941-11 CARBON 5.6K 5% 1/4W
R548 1-249-941-11 CARBON 5.6K 5% 1/4W
R549 1-249-941-11 CARBON 5.6K 5% 1/4W
R550 1-249-941-11 CARBON 5.6K 5% 1/4W
R551 1-249-941-11 CARBON 5.6K 5% 1/4W
R552 1-249-941-11 CARBON 5.6K 5% 1/4W
R553 1-249-941-11 CARBON 5.6K 5% 1/4W
R554 1-249-941-11 CARBON 5.6K 5% 1/4W
R555 1-249-923-11 CARBON 1K 5% 1/4W
R556 1-249-923-11 CARBON 1K 5% 1/4W
R559 1-249-923-11 CARBON 1K 5% 1/4W
R560 1-249-923-11 CARBON 1K 5% 1/4W
R577 1-249-520-11 CARBON 47 5% 1/4W
R578 1-249-520-11 CARBON 47 5% 1/4W
R581 1-249-429-11 CARBON 10K 5% 1/4W
R582 1-249-429-11 CARBON 10K 5% 1/4W
R583 1-249-429-11 CARBON 10K 5% 1/4W
R584 1-249-469-11 CARBON 100K 5% 1/4W
R585 1-249-469-11 CARBON 100K 5% 1/4W
R586 1-259-412-11 CARBON 220 5% 1/6W
R587 1-259-412-11 CARBON 220 5% 1/6W
R588 1-259-434-11 CARBON 1.8K 5% 1/6W
R589 1-259-434-11 CARBON 1.8K 5% 1/6W
< RELAY >
RY501 1-515-802-11 RELAY
< VIBRATOR >
X501 1-760-955-11 VIBRATOR, CRYSTAL 45MHz
************************************************************
A-4725-223-A DIG BOARD, COMPLETE (US/CND)
***************************
A-4725-249-A DIG BOARD, COMPLETE (AEP/UK)
***************************
< CAPACITOR >
C801 1-163-222-11 CERAMIC CHIP 5PF 50V
C802 1-163-224-11 CERAMIC CHIP 7PF 50V
C803 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C804 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C806 1-126-964-11 ELECT 10uF 20.00% 50V
C807 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C808 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C810 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C815 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C821 1-104-664-11 ELECT 47uF 20.00% 10V
C822 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C823 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C824 1-104-665-11 ELECT 100uF 20.00% 10V
C841 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C842 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C843 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C844 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C845 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C846 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C847 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C848 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C849 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C850 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C851 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C852 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C853 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C854 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C855 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C856 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C857 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C858 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C859 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C860 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C861 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C862 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C863 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C864 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C865 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C866 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C867 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C868 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C869 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C870 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C871 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C872 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C873 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C874 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C875 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C877 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C878 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C879 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C880 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C881 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C882 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C883 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C884 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C885 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C886 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C887 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C888 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN801 1-778-692-11 CONNECTOR, FFC/FPC 21P
CN802 1-784-370-21 CONNECTOR, FFC/FPC 11P
CN803 1-793-991-11 CONNECTOR, FFC/FPC 23P
CN804 1-793-991-11 CONNECTOR, FFC/FPC 23P
CN805 1-790-669-21 PIN, CONNECTOR (PC BOARD) 9P
CN806 1-778-998-21 PIN, CONNECTOR (PC BOARD) 3P
CN807 1-784-382-21 CONNECTOR, FFC/FPC 25P
DA DIG
