MHC-V21/V21D
8
800 :/5 W
R
800 :/5 W
R
C6301
C6322
C6505
C6506
R
800 :/5 W
R
800 :/5 W
CAPACITOR DISCHARGE FOR ELECTRIC SHOCK PREVENTION
SMPS Board (Conductor side view)
In checking the SMPS board, make 4 capacitors discharge of C6301, C6322, C6505 and C6506 for eletrical shock prevention.
HOW TO OPEN THE TRAY WHEN POWER SWITCH TURN OFF
Note 1: After the side panel and top panel are removed, this work is done.
Note 2: Please prepare the thin wire (clip etc. processed to the length of 8 cm or more).
2 Insert the clip etc.
– Top view –
DVD mechanism
deck
tray
8 cm or more
Insert the clip etc. processed to the
length of 8 cm or more in the hole
on the side of the CDM and push.
Note: Push after it inserts it
in this hole well.
– Left view –
hole
1 Remove the side panel L, R, top panel section.
(Illustration of disassembly is omitted.)
3
Ver. 1.1
