MHC-V5.GB.4-531-350-11(1)
20
GB
Transferring music from a disc
or USB device
You can easily transfer all the
music on a disc or USB A to USB B
(Synchronized Transfer). You can
also transfer a single track or audio
file during playback (REC1 Transfer).
1 Connect a USB device to the B
port.
USB device
Note
You can use a USB adaptor (not
supplied) to connect the USB device
to the unit if the USB device cannot be
plugged into the
port.
2 Select the function.
Discs:
Press CD, then load the disc.
USB:
Press USB repeatedly until “USB A
lights up on the display, then
connect the USB device containing
audio files you want to transfer to
A port.
3 Prepare the sound source.
Synchronized Transfer:
When playback is stopped, press
PLAY MODE repeatedly to select the
play mode you want.
Notes
ˎ
If you start transferring in Shue
Play (“FLDR SHUF”), the selected
play mode changes to “FLDR”
automatically.
ˎ
If you start transferring in Shue
Play (except “FLDR SHUF”), Repeat
Play or Program Play with no steps,
the selected play mode changes to
Normal Play automatically.
REC1 Transfer:
Select the track or audio file you
want to transfer, then start
playback.
4 Press REC TO USB B on the unit.
“PUSH ENTER” appears on the
display.
5 Press ENTER on the unit.
The transfer starts when
“DO NOT REMOVE” appears on the
display.
Do not remove the USB device until
the transfer is complete.
When the transfer is complete, the
system performs as follows:
Synchronized Transfer:
When the transfer is complete, the
disc or USB device stops
automatically.
REC1 Transfer:
The transfer is completed
automatically, but the disc or USB
device continues to play the next
track or file.
To stop transfer
Press .

Other manuals for Sony MHC-V5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony MHC-V5 and is the answer not in the manual?

Sony MHC-V5 Specifications

General IconGeneral
On/off switchYes
Product colorBlack
Recommended usageUniversal
Suitable for outdoor use-
Speaker type3-way
Driver diameter250 mm
Speaker positionFront
Tweeter diameter40 mm
Number of drivers3
Speaker placementFloor
Audio output channels1.0 channels
Mid-range driver diameter100 mm
Number of tweeter drivers1
Recommended amplifier power (max)240 W
Recommended amplifier power (min)0.5 W
Impedance5 Ω
Frequency range- Hz
RMS rated power1440 W
Peak Music Power Output (PMPO)15840 W
Number of amplifier channels2 channels
Power source typeAC
USB 2.0 ports quantity2
Connectivity technologyWired & Wireless
AC input voltage120 V
AC input frequency60 Hz
TypeHome audio mini system
Weight and Dimensions IconWeight and Dimensions
Depth325 mm
Width339 mm
Height908 mm
Weight18000 g
