Sony MHC-V5 Operating Instructions

29
GB
MHC-V5.GB.4-531-350-11(1)
BLUETOOTH
Setting the BLUETOOTH
standby mode
The BLUETOOTH standby mode
enables the system to turn on
automatically when you establish
the BLUETOOTH connection with a
BLUETOOTH device.
1 Press OPTIONS on the unit.
2 Press

/

repeatedly to select
“BT STBY,” then press .
3 Press

/

repeatedly to select
“ON” or “OFF,” then press .
4 Press  to turn o the system.
When the BLUETOOTH standby
mode is set to on, the system waits
for a BLUETOOTH connection even
when the system has been turned
o. When a BLUETOOTH connection
is established, the system turns on
automatically.
Note
The system cannot enter the BLUETOOTH
standby mode if the pairing registration
information has been erased.
Using “SongPal” via
BLUETOOTH
About App
A dedicated app for this model is
available on both Google Play and
App Store. Search for “SongPal” and
download the free app to find out
more about the convenient features.
BLUETOOTH technology works with
iPhone 5s, iPhone 5c, iPhone5,
iPhone 4s, iPhone 4, iPhone 3GS,
iPod touch (5th generation),
iPodtouch (4th generation).

Sony MHC-V5 Specifications

General

On/off switch	Yes
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Speaker type	3-way
Driver diameter	250 mm
Speaker position	Front
Tweeter diameter	40 mm
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Mid-range driver diameter	100 mm
Number of tweeter drivers	1
Recommended amplifier power (max)	240 W
Recommended amplifier power (min)	0.5 W
Impedance	5 Ω
Frequency range	- Hz
RMS rated power	1440 W
Peak Music Power Output (PMPO)	15840 W
Number of amplifier channels	2 channels
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
AC input voltage	120 V
AC input frequency	60 Hz
Type	Home audio mini system

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
