Sony MHC-V5 Operating Instructions

49
GB
MHC-V5.GB.4-531-350-11(1)
Additional Information
Inputs
AUDIO IN/PARTY CHAIN IN L/R:
Voltage 2 V, impedance
47kilohms
A (USB), B (USB) port:
Type A, maximum current:
500mA
Outputs
AUDIO OUT/PARTY CHAIN OUT L/R:
Voltage 2 V, impedance 47
kilohms
iPod/iPhone section
Made for
– iPhone 5s
– iPhone 5c
– iPhone 5
– iPhone 4s
– iPhone 4
– iPhone 3GS
– iPod touch (5th generation)
– iPod touch (4th generation)
Disc player section
System:
Compact disc and digital audio
system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 W
* This output is the value
measurement at a distance of
200 mm from the objective lens
surface on the Optical Pick-up
Block with 7 mm aperture.
Frequency response:
20Hz – 20kHz
Signal-to-noise ratio:
More than 90dB
Dynamic range:
More than 88dB
Tuner section
FM stereo, FM/AM superheterodyne
tuner
Antenna:
FM lead antenna
AM loop antenna
FM tuner section
Tuning range:
USA and Brazilian models:
87.5MHz - 108.0MHz (100kHz
step)
Other models:
87.5MHz - 108.0MHz (50kHz
step)
AM tuner section
Tuning range:
531kHz – 1,710kHz (9kHz step)
530kHz – 1,710kHz (10kHz step)

Sony MHC-V5 Specifications

General

On/off switch	Yes
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Speaker type	3-way
Driver diameter	250 mm
Speaker position	Front
Tweeter diameter	40 mm
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Mid-range driver diameter	100 mm
Number of tweeter drivers	1
Recommended amplifier power (max)	240 W
Recommended amplifier power (min)	0.5 W
Impedance	5 Ω
Frequency range	- Hz
RMS rated power	1440 W
Peak Music Power Output (PMPO)	15840 W
Number of amplifier channels	2 channels
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
AC input voltage	120 V
AC input frequency	60 Hz
Type	Home audio mini system

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
