Sony MHC-V5 Operating Instructions

33
GB
MHC-V5.GB.4-531-350-11(1)
Other Operations
 If one of the system is not equipped with Party Chain function
First system
Second system
Last
system
Continue the connection
until the last system
Example: When connecting using this system as the first system
ˎ
You can connect the system which is not equipped with Party Chain function
at the last system. Be sure to select the audio in function on this last system.
ˎ
You must select the first system as Party Host so that all systems are playing
the same music when Party Chain function is activated.
ˎ
In this connection, the first system and the last system are not connected.

Sony MHC-V5 Specifications

General

On/off switch	Yes
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Speaker type	3-way
Driver diameter	250 mm
Speaker position	Front
Tweeter diameter	40 mm
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Mid-range driver diameter	100 mm
Number of tweeter drivers	1
Recommended amplifier power (max)	240 W
Recommended amplifier power (min)	0.5 W
Impedance	5 Ω
Frequency range	- Hz
RMS rated power	1440 W
Peak Music Power Output (PMPO)	15840 W
Number of amplifier channels	2 channels
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
AC input voltage	120 V
AC input frequency	60 Hz
Type	Home audio mini system

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
