46
MV-700HR
Pin No.
Pin Name I/O Description
48
TDI O Serial data output terminal Not used
49
TMS I Disc lid open/close detect switches input terminal
50
STBY O Standby signal output to the coil/motor driver
51
TDO O Chip select signal output terminal Not used
52
DVDD18 - Power supply terminal (+1.8V)
53 to 59
IOA2 to IOA8 O Address signal output to the flash ROM
60, 61
IOA18, IOA19 O Address signal output to the flash ROM
62
DVSS - Ground terminal
63
APLLCAP - Connection terminal for an external capacitor
64
APLLVSS - Ground terminal
65
APLVDD3 - Power supply terminal (+3.3V)
66
XIOWR O Write enable signal output to the flash ROM
67 to 72
IOA16 to IOA11 O Address signal output to the flash ROM
73
DVDD3 - Power supply terminal (+3.3V)
74, 75
IOA10, IOA9 O Address signal output to the flash ROM
76
IOA20 O Address signal output to the flash ROM
77
XIOCS O Chip select signal output to the flash ROM
78
IOA1 O Address signal output to the flash ROM
79
XIOOE O Output enable signal output to the flash ROM
80
DVDD3 - Power supply terminal (+3.3V)
81 to 84
AD0 to AD3 I/O Data/address signal input/output terminal with the flash ROM
85
DVSS - Ground terminal
86 to 88
AD4 to AD6 I/O Data/address signal input/output terminal with the flash ROM
89
MS_INS I Memory stick insert detection signal input terminal "L": memory stick is inserted
90
ALE O Address latch enable signal output terminal Not used
91
AD7 O Address latch enable signal output terminal Not used
92
IOA17 O Address signal output to the flash ROM
93
IOA0 O Address signal output to the flash ROM
94
DVSS - Ground terminal
95
XUWR O Write enable signal output terminal Not used
96
XURD O Data read enable signal output terminal Not used
97
DVDD18 - Power supply terminal (+1.8V)
98
UP1_2 I/O Not used
99
MC O Mode control clock signal output to the D/A converter
100
UP1_4 I/O Not used
101
MD O Mode control data output to the D/A converter
102
EEP_CK O Serial data transfer clock signal output to the EEPROM
103
EEP_DA I/O Two-way data bus with the EEPROM
104
ML O Mode control latch signal output to the D/A converter
105
UP3_1 I/O Not used
106
RXD I Receive data input terminal for UART communication when data writing to flash memory
107
TXD O Transmit data output terminal for UART communication when data writing to flash memory
108
DVDD3 - Power supply terminal (+3.3V)
109
ICE I ICE mode enable signal input terminal Not used
110
XPRST I System reset signal input from the system controller
111
IR I IR control signal input terminal Not used
112
XINTO O Interrupt request signal output terminal Not used
