Sony Model MV-700HR - Page 47

47
MV-700HR
Pin No.
Pin Name I/O Description
113
DQM0 O Data mask signal output to the SD-RAM
114
DVD/CD O DVD/CD switch signal output terminal
115
RD7 I/O Two-way data bus with the SD-RAM
116
DVSS - Ground terminal
117, 118
RD6, RD5 I/O Two-way data bus with the SD-RAM
119
DVSS - Ground terminal
120, 121
RD4, RD3 I/O Two-way data bus with the SD-RAM
122
DVDD18 - Power supply terminal (+1.8V)
123 to 125
RD2 to RD0 I/O Two-way data bus with the SD-RAM
126
RD15 I/O Two-way data bus with the SD-RAM
127
DVDD3 - Power supply terminal (+3.3V)
128 to 133
RD14 to RD9 I/O Two-way data bus with the SD-RAM
134
DVSS - Ground terminal
135
RD8 I/O Two-way data bus with the SD-RAM
136
DQS1 - Not used
137
DQM1 O Data mask signal output to the SD-RAM
138
XRWE O Write enable signal output to the SD-RAM
139
XCAS O Column address strobe signal output to the SD-RAM
140
XRAS O Row address strobe signal output to the SD-RAM
141
DVDD3 - Power supply terminal (+3.3V)
142
XRCS O Chip select signal output to the SD-RAM
143
BA0 O Bank address signal output to the SD-RAM
144
DVSS - Ground terminal
145
BA1 O Bank address signal output to the SD-RAM
146
RA10 O Address signal output to the SD-RAM
147
RA0 O Address signal output to the SD-RAM
148
DVSS - Ground terminal
149 to 151
RA1 to RA3 O Address signal output to the SD-RAM
152
DVDD18 - Power supply terminal (+1.8V)
153
RVREF - Not used
154
RCLKB - Not used
155
DVDD3 - Power supply terminal (+3.3V)
156
RCLK O Serial data transfer clock signal output to the SD-RAM
157
CKE O Clock enable signal output to the SD-RAM
158
RA11 O Address signal output to the SD-RAM
159, 160
RA9, RA8 O Address signal output to the SD-RAM
161
DVSS - Ground terminal
162
RA7 O Address signal output to the SD-RAM
163
DVSS - Ground terminal
164 to 166
RA6 to RA4 O Address signal output to the SD-RAM
167
DVDD3 - Power supply terminal (+3.3V)
168
XIFBUSY O Busy signal output to the system controller
169
XIFCS I Chip select signal input from the system controller
170
SI O Serial data output to the system controller
171, 172
RD28, RD27 I/O Two-way data bus terminal Not used
173
DVDD18 - Power supply terminal (+1.8V)
174
MS_CLK O Data transfer clock signal output to a memory stick
