Pin No.
Pin Name I/O Description
175
DVSS - Ground terminal
176
MS_SDIO I/O Two-way data bus with a memory stick
177
MS_BS O Bus state signal output to a memory stick
178
SO I Serial data input from the system controller
179
SCK I Serial data transfer clock signal input from the system controller
180, 181
RD23, RD22 I/O Two-way data bus terminal Not used
182
DVDD3 - Power supply terminal (+3.3V)
183 to 188
RD21 to RD16 I/O Two-way data bus terminal Not used
189
DACVDDC - Power supply terminal (+3.3V)
190
VREF - For bandgap reference voltage terminal
191
FS - Full scale adjustment terminal
192
YUV0/CIN O Video data (bit 0) output or compensation capacitor connecting terminal Not used
193
DACVSSC - Ground terminal
194
YUV1/Y O Video data (bit 1) output or luminance signal output terminal Not used
195
DACVDDB - Power supply terminal (+3.3V)
196
YUV2/C O Video data (bit 2) output or chroma signal output terminal Not used
197
DACVSSB - Ground terminal
198
YUV3/CVBS O Video signal output terminal
199
DACVDDA - Power supply terminal (+3.3V)
200
YUV4/G O
Video data (bit 4) output or green (RGB) signal output or luminance signal output terminal
Not used
201
DACVSSA - Ground terminal
202
YUV5/B O
Video data (bit 5) output or blue (RGB) signal output or CB (component video) signal output
terminal Not used
203
YUV6/R O
Video data (bit 6) output or red (RGB) signal output or CR (component video) signal output
terminal Not used
204
DVDD3 - Power supply terminal (+3.3V)
205
VSYNC I Vertical synchronize signal input terminal Not used
206
YUV7 O Video data (bit 7) output terminal Not used
207
HSYNC I Horizontal synchronize signal input terminal Not used
208
SPMCLK I SPDIF digital audio data transfer clock signal input terminal Not used
209
SPDATA I SPDIF digital audio data input terminal Not used
210
SPLRCK I SPDIF digital audio L/R sampling clock signal input terminal Not used
211
SPBCK I SPDIF digital audio bit clock signal input terminal Not used
212
DVDD3 - Power supply terminal (+3.3V)
213
ALRCK O L/R sampling clock signal output to the D/A converter
214
ABCK O Bit clock signal (2.8224 MHz) output to the D/A converter
215
ACLK O Serial data transfer clock signal output to the D/A converter
216
DVSS - Ground terminal
217
ASDATA0 O Serial data output to the D/A converter
218 to 220
ASDATA1 to
ASDATA3
O Serial data output terminal Not used
221
DVDD18 - Power supply terminal (+1.8V)
222
ASDATA4 O Not used
223
DVSS - Ground terminal
224
MC_DATA I Serial data input terminal Not used
225
SPDIF O SPDIF digital audio signal output terminal
226
RFGND18 - Ground terminal
