Sony Model MV-700HR - Page 49

49
MV-700HR
Pin No.
Pin Name I/O Description
227
RFVDD18 - Power supply terminal (+1.8V)
228
XTALO O System clock output terminal (27 MHz)
229
XTALI I System clock input terminal (27 MHz)
230
JITFO O Output terminal of the RF jitter meter
231
JITFN I Input terminal of the RF jitter meter
232
PLLVSS - Ground terminal
233
IDACEXLP O For data PLL D/A converter low-pass filter terminal
234
PLLVDD3 - Power supply terminal (+3.3V)
235
LPFON O Data PLL loop filter output terminal
236
LPFIP I Data PLL loop filter input terminal
237
LPFIN I Data PLL loop filter input terminal
238
LPFOP O Data PLL loop filter output terminal
239
ADCVDD3 - Power supply terminal (+3.3V)
240
S_VCM - Not used
241
ADCVSS - Ground terminal
242
S_VREFP - For reference voltage terminal
243
S_VREFN - For reference voltage terminal
244
RFVDD3 - Power supply terminal (+3.3V)
245
RFRPDC O RF ripple detect output terminal
246
RFRPAC I RF ripple detect input terminal
247
HRFZC I High frequency RF ripple zero crossing terminal
248
CRTPLP O Defect level filter capacitor connecting terminal
249
RFGND - Ground terminal
250
CEQP - Not used
251
CEQN - Not used
252
OSP O RF offset cancellation capacitor connecting terminal
253
OSN O RF offset cancellation capacitor connecting terminal
254
RFGC O RF AGC loop capacitor connecting for DVD-ROM
255
IREF I Reference current input terminal
256
AVDD3 - Power supply terminal (+3.3V)
