Sony NAS-E35HD - Component Board Disassembly Steps

NAS-E35HD/SS-CE35HD
10
3-4. HP JACK BOARD, KEY (FRONT) BOARD, PANEL (FRONT) ASSY
3-5. POWER BOARD

connector
(CN303)

three screws
(BVTP3
×
6)

knob (volume)
RH
two feet (felt)
RI
panel (front) assy

screw (B2.6)
R
two screws (B2.6)
RT
four screws (B2.6)
RG
KEY (FRONT) board
RE
sheet (RM)
RB
plate
(key front PWB)

hold board

HP JACK board


screw
(BVTP3
×
6)

flexible flat cable (5 core)
(CNP601)

six screws
(BVTP3
×
6)

connector (CN909)

connector (CN901)

insulated plate
(power)


POWER board

power cord connector
(CN01)

flexible flat cable (5 core)
(CNP902)

coating clip
