NAS-E35HD/SS-CE35HD
2
NOTES ON CHIP COMPONENT REPLACEMENT
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
FLEXIBLE CIRCUIT BOARD REPAIRING
• Keep the temperature of soldering iron around 270 °C during
repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY-RELATED COMPONET WARNING!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
DAB frequency table (Band-III):
Frequency Label
174.928 MHz 5A
176.640 MHz 5B
178.352 MHz 5C
180.064 MHz 5D
181.936 MHz 6A
183.648 MHz 6B
185.360 MHz 6C
187.072 MHz 6D
188.928 MHz 7A
190.640 MHz 7B
192.352 MHz 7C
194.064 MHz 7D
195.936 MHz 8A
197.648 MHz 8B
199.360 MHz 8C
201.072 MHz 8D
202.928 MHz 9A
204.640 MHz 9B
206.352 MHz 9C
208.064 MHz 9D
209.936 MHz 10A
211.648 MHz 10B
213.360 MHz 10C
215.072 MHz 10D
216.928 MHz 11A
218.640 MHz 11B
220.352 MHz 11C
222.064 MHz 11D
223.936 MHz 12A
225.648 MHz 12B
227.360 MHz 12C
229.072 MHz 12D
230.784 MHz 13A
232.496 MHz 13B
234.208 MHz 13C
235.776 MHz 13D
237.488 MHz 13E
239.200 MHz 13F
Inputs/Outputs
AUDIO IN (stereo mini jack):
Voltage 0.8 V, impedance 22 k
(USB) port:
USB type A, Full speed USB
DMPORT:
For connecting a DIGITAL MEDIA
PORT adapter
 (headphones) jack (stereo mini jack):
Accepts headphones of 8 Ω or
more
Asian model:
AUDIO OUT (phono jacks):
Voltage 0.5 V, impedance 1 k
Speaker
Latin American model:
Speaker system:
Speaker units:
Woofer: 120 mm, cone type
Nominal impedance:
8 Ω
Dimensions (w/h/d)
Approx. 140 × 284 × 240 mm
Mass
Approx. 2.7 kg net per speaker
Other models:
Speaker system:
Speaker units:
Woofer: 120 mm, cone type
Tweeter: 40 mm, cone type
Nominal impedance:
8 Ω
Dimensions (w/h/d)
Approx. 140 × 250 × 210 mm
Mass
Approx. 2.0 kg net per speaker
General
Power requirements:
Mexican model:
120 V AC, 60 Hz
Latin American model (except
for the Mexican and Argentine models):
110 - 120 or 220 - 240 V AC,
50/60 Hz (adjustable with voltage
selector)
Other models:
220 - 240 V AC, 50/60 Hz
Power consumption:
45 W
Dimensions (w/h/d):
UK model:
Approx. 285 × 130 × 319 mm
incl. projecting parts and
controls
Other models:
Approx. 285 × 130 × 312 mm
incl. projecting parts and
controls
Mass:
Approx. 4.0 kg
Operating temperature:
+5
°C (+41 °F) to +35 °C (+95 °−F)
Operating humidity:
25 % to 80 %
Supplied accessories:
subjecttochangewithoutnotice.
(SS-CE35HD)
AM loop antenna (1)
FM lead antenna (1)
DAB lead antenna (1)
(for the UK model only)
Speaker cords (2)
Speaker pads (8)
(for the Latin American model only)
Remote control (1)
R6 (size AA) batteries (2)
DIGITAL MEDIA PORT adapter
(TDM-iP10 (M) ) (1)
(for the European model only)
iPod Dock Adapters (1 set)
(for the European model only)
Operating Instructions
FM tuner section
Tuner:
FM stereo, FM superheterodyne
tuner
Circuit system:
PLL digital frequency synthesizer
quarts lock system
Frequency range:
87.5 - 108.0 MHz (50kHz step)
Antenna:
FM lead antenna
Antenna terminals:
75 Ω unbalanced
Intermediate frequency:
10.7 MHz
AM tuner section
Tuner:
AM superheterodyne tuner
Circuit system:
PLL digital frequency synthesizer
quarts lock system
Frequency range:
European model:
531 - 1,602 kHz (with the
interval set at 9 kHz)
Latin American model:
530 - 1,710 kHz (with the
interval set at 10 kHz)
531 - 1,710 kHz (with the
interval set at 9 kHz)
Oceanian model
531 - 1,710 kHz (with the
interval set at 9 kHz)
530 - 1,710 kHz (with the
interval set at 10 kHz)
Other models:
531 - 1,602 kHz (with the
interval set at 9 kHz)
530 - 1,610 kHz (with the
interval set at 10 kHz)
Antenna:
AM loop antenna
Antenna terminals:
External antenna terminal
Intermediate frequency:
450 kHz
DAB tuner section (UK
model only)
Tuner:
DAB stereo tuner
Antenna:
DAB lead antenna
Frequency range:
Band-III: 174.928 (5A) – 239.200
(13F) MHz
CAUTION
Use of controls or adjustments or performance of procedures
other than those specifi ed herein may result in hazardous radia-
tion exposure.
This appliance is classifi ed as
a CLASS 1 LASER product.
This marking is located on the
rear or bottom exterior.
