Sony NAS-E35HD - DAB Board, DMP Board, Tuner (FM;AM)

NAS-E35HD/SS-CE35HD
12
3-8. DAB BOARD, DMP BOARD, TUNER (FM/AM)

screw
(BVTP3
×
6)

barrier (tuner)

two screws
(BVTP3
×
6)

shield plate (tuner)

two screws
(BVTP3
×
6)
RK
two screws
(B2.6)
RE
tuner (FM/AM)

bracket (DMP)

DMP board

two screws (BVTP3
×
6)
RT
two screws (BVTP3
×
6)
RI
two screws
(B2.6)
XT
two screws
(B2.6)
(UK)
(UK)
XE
bracket
(DAB)
RG
flexible flat cable (11 core)
(CN601)
RB
flexible flat cable (9 core: Russian, Chilean, Peruvian,
Mexican, Australian models/11 core: AEP, UK models)
(tuner)

flexible flat cable (11 core) (CNP812)

flexible flat cable (11 core) (CN813)
RH
nut
XB
module
(DAB tuner)
XG
DAB board
RL
connector
(CN602)
X
coaxial connector
(F type) (J601)
RM
Remove the solder.
(UK)
