NAS-E35HD/SS-CE35HD
NAS-E35HD/SS-CE35HD
4343
• Waveforms
– CD Board –
14.8 ns
3.6 Vp-p
1 V/DIV, 5 ns/DIV
RB
IC10  (1A)
(USB play mode)
2 V/DIV, 20 ns/DIV
44.3 ns
4.4 Vp-p
RT
IC2 RK (CLKIN)
(USB play mode)
2 V/DIV, 20 ns/DIV
44.3 ns
4.4 Vp-p
RG
IC12 RB (SYSCK)
(USB play mode)
1 V/DIV, 20 ns/DIV
44.3 ns
3.3 Vp-p

IC201 SB (RFACO)
(CD play mode)

IC201 VK (XTAO)
(CD play mode)
83.3 ns
3 Vp-p
1 V/DIV, 50 ns/DIV
RE
IC4 FB (XO)
(USB play mode)
200 ns
3.4 Vp-p
1 V/DIV, 100 ns/DIV
XT
IC803 RE (XOUT)
41.7 ns
1.5 Vp-p
500 mV/DIV, 20 ns/DIV
RH
IC13 FT (XTAL2)
(USB play mode)
83.3 ns
3 Vp-p
1 V/DIV, 50 ns/DIV
RI
IC9 RL (XTALO)
(USB play mode)
200 mV/DIV, 500 ns/DIV
500 mVp-p

IC201 XE (FEI)
(CD play mode)
100 mV/DIV, 500 ns/DIV
Approx.
200 mVp-p

IC201 XB (TEI)
(CD play mode)
100 mV/DIV, 500 ns/DIV
Approx.
150 mVp-p
30.5 μs
2.6 Vp-p
XB
IC803 RB (XCOUT)
1 V/DIV, 10 μs/DIV
– USB MICOM Board – – MAIN Board –
– D-AMP Board –
3.9 μs
300 mVp-p
100 mV/DIV, 2 μs/DIV
FB
IC352 RG (ROSC)
200 ns
3.5 Vp-p
1 V/DIV, 100 ns/DIV
SB
IC403 RE (XOUT)
ST
IC402 
10 V/DIV, 20 μs/DIV
75.1 μs
18 Vp-p
– DISPLAY Board –
