Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NAS-E35HD/SS-CE35HD
8585
< COIL >
L651 1-469-152-11 FERRITE, EMI (SMD) (2012)
L652 1-469-152-11 FERRITE, EMI (SMD) (2012)
L653 1-457-632-11 INDUCTOR 470uH
< RESISTOR >
R171 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R172 1-216-833-11 METAL CHIP 10K 5% 1/10W
R173 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R174 1-216-833-11 METAL CHIP 10K 5% 1/10W
R175 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R176 1-216-821-11 METAL CHIP 1K 5% 1/10W
R177 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R178 1-216-841-11 METAL CHIP 47K 5% 1/10W
R271 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R272 1-216-833-11 METAL CHIP 10K 5% 1/10W
R273 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R274 1-216-833-11 METAL CHIP 10K 5% 1/10W
R275 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R276 1-216-821-11 METAL CHIP 1K 5% 1/10W
R277 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R278 1-216-841-11 METAL CHIP 47K 5% 1/10W
R320 1-216-845-11 METAL CHIP 100K 5% 1/10W
R323 1-216-845-11 METAL CHIP 100K 5% 1/10W
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R325 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R326 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R327 1-216-864-11 SHORT CHIP 0
R652 1-216-833-11 METAL CHIP 10K 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-809-11 METAL CHIP 100 5% 1/10W
R658 1-216-809-11 METAL CHIP 100 5% 1/10W
R659 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
************************************************************
A-1498-592-A DISPLAY BOARD, COMPLETE
************************
< CAPACITOR >
C402 1-128-131-11 ELECT 22uF 20% 50V
C403 1-128-131-11 ELECT 22uF 20% 50V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-124-261-00 ELECT 10uF 20% 50V
C407 1-124-261-00 ELECT 10uF 20% 50V
C408 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C409 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C410 1-124-261-00 ELECT 10uF 20% 50V
C411 1-124-261-00 ELECT 10uF 20% 50V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C414 1-124-261-00 ELECT 10uF 20% 50V
C415 1-124-261-00 ELECT 10uF 20% 50V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C418 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C419 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C420 1-124-261-00 ELECT 10uF 20% 50V
C421 1-124-261-00 ELECT 10uF 20% 50V
C422 1-137-749-11 MYLAR 0.1uF 100V
C424 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C429 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C430 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C431 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C432 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C436 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C437 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C438 1-124-584-00 ELECT 100uF 20% 6.3V
C439 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C440 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C441 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C445 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C451 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C452 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C453 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C454 1-124-261-00 ELECT 10uF 20% 50V
< CONNECTOR >
CN401 1-815-552-11 PIN, CONNECTOR (PWB) 4P
CNP402 1-568-854-11 CONNECTOR, FFC 11P
CNP404 1-568-850-11 CONNECTOR, FFC 7P
< DIODE >
D401 6-501-817-01 DIODE MA2J1110GLS0
D402 6-501-817-01 DIODE MA2J1110GLS0
D403 6-501-817-01 DIODE MA2J1110GLS0
D404 6-501-817-01 DIODE MA2J1110GLS0
D405 6-501-817-01 DIODE MA2J1110GLS0
D406 6-501-817-01 DIODE MA2J1110GLS0
D407 6-501-817-01 DIODE MA2J1110GLS0
D408 6-501-176-01 DIODE UDZW-TE17-12B
D410 6-502-348-01 LED SLI-343Y8CT32 (HDD)
D411 6-502-348-01 LED SLI-343Y8CT32 (USB)
D412 6-502-348-01 LED SLI-343Y8CT32 (CD)
D413 6-502-348-01 LED SLI-343Y8CT32 (AUDIO IN)
D414 6-502-348-01 LED SLI-343Y8CT32 (DMPORT)
D415 6-502-348-01 LED SLI-343Y8CT32 (TUNER)
< FLUORESCENT INDICATOR TUBE >
FL401 1-519-997-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC401 8-759-548-62 IC SN74LV123ANSR
IC402 8-759-100-96 IC uPC4558G2
IC403 A-1552-984-A IC R5F3640DDFA (for SERVICE)
IC404 6-702-302-01 IC
TK11133CSCL-G
< TRANSISTOR >
Q401 8-729-307-58 TRANSISTOR 2SC1775A-E
Q402 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q403 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q404 8-729-620-07
TRANSISTOR 2SC3052EF-T1-LEF
Q405 8-729-230-27 TRANSISTOR 2SA1213Y-TE12L
Q406 8-729-807-51 TRANSISTOR 2SD1623-S
Q407 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q408 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q410 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q411 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
DISPLAYDAB
