Specifications
167
Appendix
Input/Output connectors
Media Block
Card slots
Type: Express Card34
Number of slots: 2
Connector: Conforms to PCMCIA Express Card
Standard
Writing rate
50 Mbps or more
Reading rate
50 Mbps or more
Inputs/Outputs
Signal inputs
AUDIO IN CH1/CH2: XLR type, 3-pin, female
–60 dBu/–4 dBu (0 dBu=0.775 Vrms)
MIC IN: XLR type, 5-pin, female
–60 dBu
GENLOCK IN: BNC type
1.0 Vp-p, 75 Ω, unbalanced
TC IN: BNC type
0.5 V to 18 Vp-p, 10 kΩ
Signal outputs
VIDEO OUT: BNC type
HDMI: Type A, 19-pin
HD/SD SDI OUT 1/2: BNC type
AUDIO OUT: XLR type, 5-pin, male
0 dBu
TC OUT: BNC type
1.0 Vp-p, 75 Ω
EARPHONE (stereo minijack)
8 Ω, –∞ to –18 dBs variable
Others
DC IN: XLR type, 4-pin, male
11 to 17 V DC
DC OUT: 4-pin
11 to 17 V DC, maximum rated current:
0.5 A
LENS: 12-pin
Supplying power to the lens
11 to 17 V DC, maximum rated current:
1.0 A
REMOTE: 8-pin
LIGHT: 2-pin
USB: 4-pin
i.LINK (HDV/DV): 6-pin, complies with
IEEE1394
VF: 26-pin, rectangular, 20-pin round
For wireless receiver: D-sub 15-pin
Lens Block (PMW-320K Only)
Focal length
5.8 mm (
1
/
4
inches) to 93 mm (3
3
/
4
inches)
(equivalent to 31.4 mm (1
1
/
4
inches) to 503 mm
(19
7
/
8
inches) on 35 mm (1
7
/
16
inches) lens)
Zoom
Servo/Manual selectable
Zoom ratio
16×
Maximum relative aperture
1:1.9
Iris
Auto/Manual selectable
F1.9 to F16 and C (close)
Focus
Auto/Manual selectable
Ranges:
800 mm (31
1
/
2
inches) to ∞ (Macro OFF)
50 mm (2 inches) to ∞ (Macro ON, Wide)
Filter thread
M82 mm, pitch 0.75 mm
Macro
ON/OFF switchable
