Sony PMW-320K - Gain Value

Viewfinder Screen Display
33
Chapter 1 Overview
5600: When the assignable switch to which Color
Temp SW 5600K has been assigned is on
6300: When the assignable switch to which Color
Temp SW 6300K has been assigned is on
m Gain value
Indicates the gain value (in dB) of the video
amplifier, as set by the GAIN selector.
n Recording status indication
When the Rec Status Indicator item of the
Operation menu is set to [On], B marks are
displayed as the recording proceeds.
o Shutter
Indicates the shutter speed or the shutter mode.
For details, see “Setting the Electronic Shutter”
(page 54).
p Audio level meters
Indicate the audio levels of channel 1 and channel
2.
q Remaining media capacity
Indicates the recording time remaining for each of
the media loaded in the slots. The available time
for recording with the current video format
(recording bit rate) is calculated according to the
remaining space of each media and indicated in
time units of minutes. A lock icon appears if the
media is write-protected.
r Histogram
Shows a pixel distribution of video luminance
(HD mode only).
s Iris position (when the lens is mounted)
Indicates the iris position and the setting for iris
override (reference value for the lens iris) (see
page 56).
The iris override setting is indicated by four
segments indicator as follows.
Reference
value
Indicator
+0.25
x
Lower left segment is lit in grey.
+0.5 x
x
Left two segments are lit in grey.
+0.75 x
xx
Left two segments and lower
right segment are lit in grey.
+1 xx
xx
All segments are lit in grey.
–0.25
s
Lower left segment is lit in
white.
–0.5 s
s
Left two segments are lit in
white.
–0.75 s
ss
Left two segments and lower
right segment are lit in white.
–1 ss
ss
All segments are lit in white.
Reference
value
Indicator
