Sony PMW-320K - Manually Adjusting the Audio Level of the MIC in Connector; Recording Audio on Channels 3 and 4

Adjusting the Audio Level
60
Chapter 3 Adjustments and Settings
2 Set the AUDIO SELECT switch(es)
corresponding to the channel(s) selected
in step 1 to MANUAL.
3 With the LEVEL control(s) for the
channel(s) selected in step 1, adjust so
that the audio level meter shows up to
–20 dB for a normal input volume.
Correspondence between recording level
adjustments and audio level controls
On MAINTENANCE >Audio in the setup menu,
you can select which audio level control controls
the audio recording level of the input to each of
the AUDIO IN CH-1/CH-2 connectors. The
correspondences between the settings of the menu
items and the controls are as follows.
Rear1/WRR Level: Channel 1 recording level
Rear2/WRR Level: Channel 2 recording level
Note
When you have operation of the LEVEL (CH1/CH2)
knobs and MIC LEVEL control linked together, if the
MIC LEVEL control is set to 0, the audio signals on
channels 1 and 2 cannot be recorded. Check the position
of the MIC LEVEL control before adjusting the LEVEL
(CH1/CH2) knobs.
1 Set either or both of the AUDIO IN
switch(es) to FRONT.
2 Set the AUDIO SELECT switch(es) for
the desired channel(s) selected in step 1
to MANUAL.
3 Turn the MIC LEVEL control, and
adjust so that the audio level meter
shows up to –20 dB for a normal input
volume.
Correspondence between recording level
adjustments and audio level controls
On MAINTENANCE >Audio in the setup menu,
you can select which audio level control controls
the audio recording level of the front microphone
input. The correspondences between the settings
of the menu items and the controls are as follows.
MIC CH1 Level: Channel 1 recording level
MIC CH2 Level: Channel 2 recording level
Note
When you have operation of the MIC LEVEL control
and LEVEL (CH1/CH2) knobs linked together, if the
LEVEL (CH1/CH2) controls are set to 0, the audio
signals on channels 1 and 2 cannot be recorded. Check
the position of the LEVEL (CH1/CH2) knobs before
adjusting the MIC LEVEL control.
Selecting the recorded audio
You can select the audio recorded on audio
channels 3 and 4 with the AUDIO IN CH3/CH4
switches.
Setting Knob
Side1 LEVEL (CH1) knob
Front MIC LEVEL control
Front+Side1 LEVEL (CH1) knob and MIC
LEVEL control (linked
operation)
Setting Knob
Side2 LEVEL (CH2) knob
Front MIC LEVEL control
Front+Side2 LEVEL (CH2) knob and MIC
LEVEL control (linked
operation)
Manually Adjusting the Audio
Level of the MIC IN Connector
Setting Knob
Side1 LEVEL (CH1) knob
Front MIC LEVEL control
Front+Side1 LEVEL (CH1) knob and MIC
LEVEL control (linked
operation)
Setting Knob
Side2 LEVEL (CH2) knob
Front MIC LEVEL control
Front+Side2 LEVEL (CH2) knob and MIC
LEVEL control (linked
operation)
Recording Audio on Channels 3
and 4
