Sony PVM-9L1 - Speaker; Picture Tube and Bezel Assembly

1-5
PVM-9L1
1-3-7. Speaker
. Remove the rear cover assembly. (Refer to 1-3-3.)
. Remove the bottom and A board. (Refer to 1-3-6.)
1-3-8. Picture Tube and Bezel Assembly
. Remove the rear cover assembly. (Refer to 1-3-3.)
. Remove the C board. (Refer to 1-3-5.)
. Remove the bottom and A board. (Refer to 1-3-6.)
1 Two screws
(+BVTP 3 x 12)
2 Speaker
Cushion
Bottom, A board
1 Four self
tapping screws
3 Front chassis assembly
4 Picture tube
2 Bezel assembly
Cushion
