KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-40W4100
P/N DISCRIPTION LOCATION TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-19 UNDER BAR-2 LCD-PNL-2 BOTTOM FRAME-4
27
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
TERMINAL-2 MIAN BRKT-1 LIGHT GUIDE-1
4
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-6 STAND PLATE-4 STAND TO PNL-4
14
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5
5
2-580-602-01 SCREW, +PSW M4X12
STAND NECK-2
2
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 EDGE COVER-2
16
2-580-606-01 SCREW, +PSW M5X8
VESA-8
8
2-580-600-01 SCREW, +PSW M4X8
SPINE-6
6
2-580-629-01 SCREW, +BVST 3X8
(none)
0
2-580-628-01 SCREW, +BVST 3X6
IP5Z-6 AC BRKT-1 LVDS-2 MAIN BRKT-4 BU-9 UNDER COVER-1
23
4-635-966-01 SCREW (HEX)
BU SHLD-2
2
2-596-649-01 +KTT 3X10 (S TYPE)
AC INLET-2
2
7-682-948-01 SCREW, +PSW 3X8
PNL HEAT SINK-3
3
2-580-591-01 SCREW, +PSW M3X5
(none)
0
2-650-770-11 SLIDE, CLAMP
7
TAPE (D4)
2
TAPE (LCD)
9
KDL-46W4100/46W4150
P/N DISCRIPTION LOCATION TOTAL
2-580-640-01 SCREW, +BVTP2 4X16
REAR COVER-21 UNDER BAR-2 LCD-PNL-2 BOTTOM FRAME-4
29
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
TERMINAL-2 MIAN BRKT-1 LIGHT GUIDE-1
4
2-580-608-01 SCREW, +PSW M5X16
REAR COVER-6 STAND PLATE-4 STAND TO PNL-4
14
2-580-607-01 SCREW, +PSW M5X12
STAND NECK-5
5
2-580-602-01 SCREW, +PSW M4X12
STAND NECK-2
2
2-580-644-01 SCREW, +KTP2 3X8
STAND PLATE-14 EDGE COVER-2
16
2-580-606-01 SCREW, +PSW M5X8
SPINE-10 CENTER FRAME-2 VESA TOP-2 VESA BOTTOM-4 BOTTOM FRAME TO PNL-1
19
2-580-600-01 SCREW, +PSW M4X8
(none)
0
2-580-629-01 SCREW, +BVST 3X8
IP5Z-6 AC BRKT-1 LVDS-1 MAIN BRKT-3 BU-9 UNDER COVER-1 G SUPPORT-2
23
2-580-628-01 SCREW, +BVST 3X6
(none)
0
4-635-966-01 SCREW (HEX)
BU SHLD-2
2
2-596-649-01 +KTT 3X10 (S TYPE)
AC INLET-2
2
7-682-948-01 SCREW, +PSW 3X8
PNL HEAT SINK-3
3
2-580-591-01 SCREW, +PSW M3X5
LVDS-1
1
2-650-770-11 SLIDE, CLAMP
7
TAPE (D4)
2
TAPE (LCD)
9
4-6. SCREW LEGEND
