42
KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-46W4100/46W4150 ONLY
H Boards/
Speaker Harness
CENTER Main Harness on panel
RED UL Tape is positioned under boss
on panel and above slot in panel bottom.
