KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-46W4100/46W4150 ONLY
H Boards/Speaker Harness
Apply harness to Panel TOP edge. To center Harness, position
RED UL tape over center of panel. Use screw on panel as
Reference where center of panel is. Apply Sheet core C over
Red UL tape once harness is centered. Apply Sheet Core C
over Black UL Tape on Harness (guides).
Center of panel
1
2
3
