KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
101
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
When ordering parts by reference
number, please include the board name.
REF. NO. PART NO. DESCRIPTION VALUES
BU
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
NOTE: The components identifi ed by a red outline and a mark
contain confi dential information. Specifi c instructions must be
adhered to whenever these components are repaired and/or
replaced.
See Appendix A: Encryption Key Components in the back of this
manual.
SECTION 5: ELECTRICAL PARTS LIST
BU
A-1547-089-A BU BOARD, COMPLETE
(KDL-40W4100 ONLY)
A-1547-090-A BU BOARD, COMPLETE
(KDL-46W4100/46W4150 ONLY)
CAPACITOR
C1001 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C1002 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1003 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1004 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1005 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1052 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1053 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1101 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1102 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1103 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1104 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1204 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C1210 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1211 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1212 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1213 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1214 1-114-130-11 CERAMIC CHIP 1μF 10% 6.3V
C1215 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1223 1-218-953-11 RES-CHIP 1K 5% 1/16W
C1301 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1302 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1303 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1304 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1305 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1306 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1307 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1308 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1309 1-114-325-11 CERAMIC CHIP 0.1μF 10% 25V
C1310 1-100-766-21 ELECT CHIP 47μF 20% 16V
C1401 1-114-353-11 CAP, CERAMIC 0.01μF X7R (1410)
C1403 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C1405 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C1411 1-100-905-11 CERAMIC CHIP 0.001μF 10% 50V
C1420 1-100-912-11 CERAMIC CHIP 1μF 10% 25V
C1421 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2001 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2003 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C2004 1-112-777-11 CERAMIC CHIP 0.01μF 10% 25V
C2006 1-114-354-11 CAP, CERAMIC 0.1μF X7R (1410)
C2008 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2009 1-135-366-11 ELECT CHIP 100μF 20% 16V
C2010 1-114-354-11 CAP, CERAMIC 0.1μF X7R (1410)
C2011 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2013 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2015 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2016 1-135-366-11 ELECT CHIP 100μF 20% 16V
C2018 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2019 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2021 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2022 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2023 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2024 1-114-354-11 CAP, CERAMIC 0.1μF X7R (1410)
C2025 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2026 1-112-781-11 CERAMIC CHIP 1μF 10% 10V
C2027 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2028 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2029 1-114-354-11 CAP, CERAMIC 0.1μF X7R (1410)
C2030 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2031 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2032 1-114-331-11 CERAMIC CHIP 4.7μF 10% 10V
C2033 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
C2034 1-135-366-11 ELECT CHIP 100μF 20% 16V
C2035 1-100-916-11 CERAMIC CHIP 0.1μF 10% 16V
