23
KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-40W4100 ONLY
Combination H Boards/Speaker Harness
Apply Sheet Core C to Harness. Use BLACK UL
TAPE on Harness as guide where to apply
Sheet Core C. Apply LCD Tape over speaker wires.
Use Black UL tape as guide where to apply tape.
DO NOT apply LCD tape over hole in speaker!
2
4
To Next Page
