54
KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-46W4100/46W4150 ONLY
5P Connector Assy Routing
Dress 5P Conn Assy
in Slide Clamp as shown
3
4
5
6
9
