KDL-40W4100/46W4100/46W4150
KDL-40W4100/46W4100/46W4150
KDL-46W4100/46W4150 ONLY
LVDS Cable Routing
46W4100 LVDS Cable has
TWO WHITE UL TAPE Band
Apply 3x8mm screw to secure LVDS metal
tab to main bracket.
Dress LVDS Cable in
Slide Clamp
3
4
5
6
9
Apply 3x5mm screw to secure LVDS metal
tab to panel.
