Sony RMT-D142P - Board; Switching Regulator

2-5
2-9. IF-89 BOARD
3 FMM-41 flexible boar
d
(CN203, 26P)
2 FMO-4 flexible board
(CN204, 9P)
1 FMS-17 flexible board
(CN201, 5P)
9 Two screws
(SUMIEITE(B3)+BV)
0 IF-89 board
7 Connector (PF-127, CN401, 13P)
7 Connector (FF-206, CN406, 3P)
5 Connector (CN402, 7P)
6 Connector (CN102, 6P)
4 Connector (CN101, 9P)
2-10. SWITCHING REGULATOR
3 Therr screws
(SUMIEITE(B3)+BV)
1 Connector (CN101, 2P)
1 Connector (FF-127, CN201, 13P)
4 Power block
