DVP-NS325/NS330/NS333/NS430/NS433/NS530/NS725P/NS730P
4-39 4-40
MB-128 (MECHA DECK) PRINTED WIRING BOARD
• : Uses unleaded solder.
MS-128 BOARD
ER-21 BOARD
(NS330/NS333/NS430/NS433)
AF-98 board
(AUDIO/VIDEO OUT)
MB-108 board
(DVD/OD RF AMP, SERVO,
MOTORMDRIVE, AD DECODER,
SYSTEM CONTROL,
AUDIO ADC, PLL)
SW-384 board
(SWITCH)
MS-128 board
(LOADING MOTOR)
Power board
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
For printed wiring board
MECHA DECK
MS-128
C
B
A
1
2
8765
43
To Next Page
