Sony SAT-A55P User Manual

— 24 —
SAT-A55P/B55P
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
D331 8-719-067-40 DIODE STZ6.8N-T146
D502 8-719-404-50 DIODE MA111-TX
D503 8-719-404-50 DIODE MA111-TX
D504 8-719-404-50 DIODE MA111-TX
D505 8-719-404-50 DIODE MA111-TX
! D506 8-719-064-74 DIODE P3100SB
D507 8-719-067-40 DIODE STZ6.8N-T146
D520 8-719-404-50 DIODE MA111-TX
D531 8-719-067-40 DIODE STZ6.8N-T146
D532 8-719-045-67 DIODE RB731U-T108
D550 8-719-978-33 DIODE UDZSTE-176.8B
D551 8-719-914-43 DIODE DAN202K-T-146
D552 8-719-914-43 DIODE DAN202K-T-146
D553 8-719-404-50 DIODE MA111-TX
D554 8-719-404-50 DIODE MA111-TX
D555 8-719-404-50 DIODE MA111-TX
D601 8-719-510-43 DIODE S1WB60B
D620 8-719-063-73 DIODE D1NL20U-TR
D621 8-719-063-73 DIODE D1NL20U-TR
D623 8-719-063-73 DIODE D1NL20U-TR
D624 8-719-031-79 DIODE D5SC4M
D630 8-719-404-50 DIODE MA111-TX
D640 8-719-063-73 DIODE D1NL20U-TR
D700 8-719-063-73 DIODE D1NL20U-TR
D701 8-719-059-24 DIODE P6KE200A
D705 8-719-063-73 DIODE D1NL20U-TR
D706 8-719-063-73 DIODE D1NL20U-TR
D800 8-719-067-40 DIODE STZ6.8N-T146
D801 8-719-067-40 DIODE STZ6.8N-T146
D802 8-719-067-40 DIODE STZ6.8N-T146
D803 8-719-067-40 DIODE STZ6.8N-T146
D850 1-163-224-11 CERAMIC CHIP 7pF 0.25pF 50V
D851 8-719-031-68 DIODE HVU359TRF
FUSE
! F500 1-576-393-11 FUSE
! F501 1-576-393-11 FUSE
! F601 1-532-745-11 FUSE, GLASS TUBE 3.15A/125V
! F620 1-532-745-11 FUSE, GLASS TUBE 3.15A/125V
FERRITE BEAD
FB105 1-412-911-11 FERRITE 0µH
FB152 1-412-911-11 FERRITE 0µH
FB270 1-412-911-11 FERRITE 0µH
FB300 1-412-911-11 FERRITE 0µH
FB301 1-412-911-11 FERRITE 0µH
FB302 1-412-911-11 FERRITE 0µH
FB304 1-412-911-11 FERRITE 0µH
! FB500 1-412-911-11 FERRITE 0µH
! FB501 1-412-911-11 FERRITE 0µH
FB520 1-412-911-11 FERRITE 0µH
FB601 1-412-911-11 FERRITE 0µH
FB602 1-412-911-11 FERRITE 0µH
FB801 1-412-911-11 FERRITE 0µH
FB850 1-414-231-22 FERRITE 0µH
FB900 1-414-231-22 FERRITE 0µH
(SAT-A55P ONLY)
FB970 1-414-231-22 FERRITE 0µH
IC
IC001 8-742-205-30 HYB IC SBX3081-01(30)
IC100 8-759-693-15 IC TC58FVB160FT-85-SV10701
IC101 8-759-687-40 IC IS41LV16256-35T
IC104 8-759-684-72 IC M24C64-WMN6T(A)
IC110 8-759-663-50 IC TMS320AV7100-2.7
IC120 8-759-573-19 IC MT48LC1M16A1TG-7S
IC150 8-759-471-57 IC AT82002159-0T1T
IC160 8-759-675-91 IC ISPLSI2032VE-135LJ44B6
IC171 8-759-663-27 IC LP3470M5X-4.38
IC206 8-759-700-07 IC NJM2903M-TE2
IC240 8-759-100-96 IC NJM4558M-TE2
IC260 8-759-231-53 IC L7805CV
! IC290 8-759-641-88 IC MC34063ABN
IC300 8-759-640-14 IC TK15420MTL
IC301 8-759-640-14 IC TK15420MTL
IC500 8-759-469-41 IC 73K222BL-IH
! IC501 8-749-017-37 IC CPC1035NTR
IC520 8-759-553-77 IC MN150414SA1
IC622 8-759-663-02 IC L7905CV
! IC623 8-719-936-96 PHOTO COUPLER PC817-B
IC624 8-759-198-31 IC TL431CLP-Z
IC640 8-759-231-58 IC L7812CV
! IC700 8-759-490-02 IC TOP224Y-BB
IC800 8-759-594-77 IC CS4338KS
IC801 8-759-636-55 IC M5218AFP-T1
IC802 8-759-636-55 IC M5218AFP-T1
IC850 8-759-073-52 IC TC74AC04F-EL
IC910 8-759-594-68 IC CS4924CL
(SAT-A55P ONLY)
JACK
J151 1-568-267-21 JACK
! J500 1-770-671-11 JACK, MODULAR
J800 1-770-546-21 JACK, PIN 6P
