— 25 —
SAT-A55P/B55P
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
COIL
L110 1-408-608-31 INDUCTOR 27µH
L111 1-408-608-31 INDUCTOR 27µH
L112 1-408-608-31 INDUCTOR 27µH
L210 1-406-669-11 INDUCTOR 470µH
L290 1-406-669-11 INDUCTOR 470µH
L300 1-408-605-31 INDUCTOR 15µH
L301 1-408-605-31 INDUCTOR 15µH
L302 1-408-613-31 INDUCTOR 68µH
L303 1-408-608-31 INDUCTOR 27µH
L304 1-410-471-11 INDUCTOR 12µH
L625 1-406-659-11 INDUCTOR 10µH
L800 1-408-608-31 INDUCTOR 27µH
L805 1-408-608-31 INDUCTOR 27µH
L850 1-414-108-11 INDUCTOR 0.68µH
IC LINK
PS260 1-532-605-00 LINK, IC 0.4A/150V
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q160 8-729-027-23 TRANSISTOR DTA114EKA-T146
(SAT-A55P ONLY)
Q190 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q199 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q201 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q202 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q203 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q204 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q240 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q241 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q290 8-729-019-01 TRANSISTOR 2SD2394-EF
Q301 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q304 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q520 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q521 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q522 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q550 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q551 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q630 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q631 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q632 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q650 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q651 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q652 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q653 8-729-019-01 TRANSISTOR 2SD2394-EF
Q654 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q655 8-729-140-96 TRANSISTOR 2SD774-T-4
Q690 8-729-019-01 TRANSISTOR 2SD2394-EF
Q691 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q692 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q693 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q800 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q801 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
(SAT-A55P ONLY)
Q802 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
(SAT-A55P ONLY)
RESISTOR
R010 1-216-813-11 RES-CHIP 220 5% 1/16W
R011 1-216-813-11 RES-CHIP 220 5% 1/16W
R012 1-216-813-11 RES-CHIP 220 5% 1/16W
R013 1-216-817-11 RES-CHIP 470 5% 1/16W
R100 1-216-833-11 RES-CHIP 10K 5% 1/16W
R101 1-216-821-11 RES-CHIP 1K 5% 1/16W
R102 1-216-817-11 RES-CHIP 470 5% 1/16W
R103 1-216-817-11 RES-CHIP 470 5% 1/16W
R104 1-216-817-11 RES-CHIP 470 5% 1/16W
R105 1-216-818-11 RES-CHIP 560 5% 1/16W
R106 1-216-818-11 RES-CHIP 560 5% 1/16W
R107 1-216-818-11 RES-CHIP 560 5% 1/16W
R108 1-208-817-11 METAL CHIP 30K 0.50% 1/10W
R109 1-216-833-11 RES-CHIP 10K 5% 1/16W
R110 1-216-833-11 RES-CHIP 10K 5% 1/16W
R111 1-216-833-11 RES-CHIP 10K 5% 1/16W
R112 1-216-833-11 RES-CHIP 10K 5% 1/16W
R115 1-216-833-11 RES-CHIP 10K 5% 1/16W
R119 1-216-864-11 SHORT
R123 1-216-864-11 SHORT
R137 1-216-833-11 RES-CHIP 10K 5% 1/16W
R138 1-216-833-11 RES-CHIP 10K 5% 1/16W
R139 1-216-801-11 RES-CHIP 22 5% 1/16W
R150 1-216-833-11 RES-CHIP 10K 5% 1/16W
R152 1-216-833-11 RES-CHIP 10K 5% 1/16W
R154 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R160 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R161 1-216-864-11 SHORT
R162 1-216-864-11 SHORT
R164 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R165 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R170 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R172 1-216-833-11 RES-CHIP 10K 5% 1/16W
R188 1-216-833-11 RES-CHIP 10K 5% 1/16W
R190 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R191 1-216-845-11 RES-CHIP 100K 5% 1/16W
A
