SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-17
R379 1-249-433-11 CARBON 22K 5% 1/4W
R380 1-216-308-00 RES-CHIP 4.7 5% 1/10W
(EXCEPT ED616/ED818/ED915)
R380 1-216-005-00 RES-CHIP 15 5% 1/10W
(ED616/ED818/ED915)
R382 1-216-081-00 RES-CHIP 22K 5% 1/10W
(ED616/ED818/ED915)
R383 1-216-001-00 RES-CHIP 10 5% 1/10W
(ED616/ED818/ED915)
R384 1-216-089-00 RES-CHIP 47K 5% 1/10W
(ED616/ED818/ED915)
R385 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(ED515/ED616)
R386 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R387 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R400 1-216-021-00 RES-CHIP 68 5% 1/10W
R401 1-249-410-11 CARBON 270 5% 1/4W
(EZ715/EZ717)
R402 1-249-408-11 CARBON 180 5% 1/4W
(ED115/ED215/ED616/
ED817/ED818/ED915/ED919/EZ717)
R404 1-249-437-11 CARBON 47K 5% 1/4W
R405 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-403-11 CARBON 68 5% 1/4W
R411 1-249-419-11 CARBON 1.5K 5% 1/4W
R414 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R415 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R416 1-249-427-11 CARBON 6.8K 5% 1/4W
R417 1-249-431-11 CARBON 15K 5% 1/4W
R418 1-216-089-00 RES-CHIP 47K 5% 1/10W
R424 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R425 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R426 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R427 1-216-077-91 RES-CHIP 15K 5% 1/10W
R428 1-216-089-00 RES-CHIP 47K 5% 1/10W
R451 1-249-413-11 CARBON 470 5% 1/4W
R452 1-216-049-00 RES-CHIP 1K 5% 1/10W
R453 1-216-049-00 RES-CHIP 1K 5% 1/10W
R454 1-216-049-00 RES-CHIP 1K 5% 1/10W
R455 1-249-417-11 CARBON 1K 5% 1/4W
R457 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R458 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R459 1-216-085-00 RES-CHIP 33K 5% 1/10W
R526 1-249-437-11 CARBON 47K 5% 1/4W
R601 1-214-949-21 METAL 3.3M 1% 1/2W
R602 1-247-883-00 CARBON 150K 5% 1/4W
R603 1-247-891-00 CARBON 330K 5% 1/4W
R604 1-249-430-11 CARBON 12K 5% 1/4W
R605 1-249-419-11 CARBON 1.5K 5% 1/4W
R606 1-215-444-00 METAL 9.1K 1% 1/4W
R607 1-249-428-11 CARBON 8.2K 5% 1/4W
!R611 1-260-364-11 CARBON 1M 5% 1/2W
R612 1-208-789-11 METAL CHIP 2K 0.5% 1/10W
R613 1-249-406-11 CARBON 120 5% 1/4W
R614 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R615 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R616 1-249-401-11 CARBON 47 5% 1/4W
R617 1-249-417-11 CARBON 1K 5% 1/4W
R618 1-249-409-11 CARBON 220 5% 1/4W
!R640 1-219-153-11 FUSIBLE 10 5% 1/4W
!R641 1-219-153-11 FUSIBLE 10 5% 1/4W
R643 1-216-353-00 METAL OXIDE 2.2 5% 1W
R647 1-215-465-00 METAL 68K 1% 1/4W
R648 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R649 1-249-401-11 CARBON 47 5% 1/4W
R651 1-215-459-00 METAL 39K 1% 1/4W
R668 1-216-073-00 RES-CHIP 10K 5% 1/10W
R701 1-247-807-31 CARBON 100 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-216-295-00 SHORT 0
R704 1-249-413-11 CARBON 470 5% 1/4W
R708 1-216-295-00 SHORT 0
R709 1-216-113-00 RES-CHIP 470K 5% 1/10W
R710 1-216-097-11 RES-CHIP 100K 5% 1/10W
R711 1-249-433-11 CARBON 22K 5% 1/4W
R727 1-216-295-00 SHORT 0
(ED915/ED919/EZ715/EZ717)
R728 1-216-295-00 SHORT 0
!R730 1-240-307-81 FUSIBLE 560 5% 1/4W
R733 1-249-413-11 CARBON 470 5% 1/4W
(ED915/ED919/EZ715/EZ717)
R734 1-249-413-11 CARBON 470 5% 1/4W
(ED915/ED919/EZ715/EZ717)
R738 1-216-295-00 SHORT 0
R740 1-216-035-00 RES-CHIP 270 5% 1/10W
(ED815/ED817/
ED818/ED915/ED919/EZ715/EZ717)
R742 1-216-047-91 RES-CHIP 820 5% 1/10W
R901 1-216-097-11 RES-CHIP 100K 5% 1/10W
(ED815/ED817/
ED818/ED915/ED919/EZ715/EZ717)
R902 1-216-097-11 RES-CHIP 100K 5% 1/10W
(ED815/ED817/
ED818/ED915/ED919/EZ715/EZ717)
R905 1-216-041-00 RES-CHIP 470 5% 1/10W
(ED815/ED817/
ED818/ED915/ED919/EZ715/EZ717)
R906 1-216-041-00 RES-CHIP 470 5% 1/10W
R908 1-216-023-00 RES-CHIP 82 5% 1/10W
R909 1-249-407-11 CARBON 150 5% 1/4W
R910 1-216-025-11 RES-CHIP 100 5% 1/10W
R913 1-249-408-11 CARBON 180 5% 1/4W
R914 1-216-021-00 RES-CHIP 68 5% 1/10W
<SWITCH>
S101 1-571-958-11 SWITCH, PUSH (1 KEY)
S102 1-771-155-11 SWITCH, ROTARY
S454 1-771-574-21 SWITCH, TACTILE
S458 1-771-574-21 SWITCH, TACTILE (EZ715/EZ717)
S459 1-771-574-21 SWITCH, TACTILE
S465 1-771-574-21 SWITCH, TACTILE
S466 1-771-574-21 SWITCH, TACTILE
S467 1-771-574-21 SWITCH, TACTILE
S468 1-771-574-21 SWITCH, TACTILE (ED115/ED215/
ED616/ED817/ED818/ED915/ED919/EZ717)
MA-402
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
To Next Page
