SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-18
<TRANSFORMER>
T371 1-423-414-11 TRANSFORMER, BIAS OSCILLATION
T372 1-423-415-11 TRANSFORMER, BIAS OSCILLATION
(ED616/ED818/ED915)
!T600 1-435-790-11 TRANSFORMER, CONVERTER
<TUNER>
TU701 1-693-544-11 TUNER, (BTF-3MG403)
(EXCEPT ED919)
TU701 1-693-543-11 TUNER (BTF-3MG412) (ED919)
<VARISTOR>
!VDR600 1-801-267-31 VARISTOR TNR10V431K660
<CRYSTAL>
X001 1-767-897-12 VIBRATOR, CRYSTAL 24.576 MHz
X101 1-767-855-11 VIBRATOR, CRYSTAL 10MHz
X102 1-579-463-11 VIBRATOR, CRYSTAL 32.768 KHz
X151 1-767-856-11 VIBRATOR, CRYSTAL 17.734475 MHz
X152 1-767-857-11 VIBRATOR, CRYSTAL 14.31818 MHz
(ED919)
X201 1-760-708-11 VIBRATOR, CRYSSTAL 4.433619 MHZ
X202 *1-760-709-11 VIBRATOR, CRYSTAL 3579.545 KHz
(EXCEPT EZ111/EZ212/EZ414)
A-6713-875-A NK-11 BOARD COMPLETE
(ED915/ED919/EZ715NZ/EZ717NZ)
*********************
< CAPACITOR >
C003 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C004 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C005 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C006 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C007 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C008 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C009 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C010 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C011 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C012 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C013 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C014 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C015 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
C016 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C017 1-110-501-11 CERAMIC CHIP 0.33uF 10.00% 16V
C018 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C019 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C020 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C021 1-113-642-11 TANTALUM CHIP 47uF 10.00% 10V
C022 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C023 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
< CONNECTOR >
* CN001 1-691-183-11 CONNECTOR (BOARD TO BOARD) 13P
< DIODE >
D001 8-719-066-72 DIODE BB135
< FERRITE BEAD >
FB001 1-543-813-21 FERRITE 0uH
FB002 1-543-813-21 FERRITE 0uH
FB003 1-543-813-21 FERRITE 0uH
< IC >
IC001 8-759-526-43 IC TDA9874H/V1, 118
< COIL >
L006 1-412-945-11 INDUCTOR 3.3uH
< IC LINK >
!PS001 1-576-122-21 LINK, IC (0.4A)
< RESISTOR >
R001 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R002 1-216-073-00 METAL CHIP 10K 5% 1/10W
R003 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R004 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R005 1-216-041-00 METAL CHIP 470 5% 1/10W
R006 1-216-041-00 METAL CHIP 470 5% 1/10W
R007 1-216-001-00 METAL CHIP 10 5% 1/10W
R008 1-216-001-00 METAL CHIP 10 5% 1/10W
R009 1-216-001-00 METAL CHIP 10 5% 1/10W
R010 1-216-001-00 METAL CHIP 10 5% 1/10W
R011 1-216-304-11 METAL CHIP 3.3 5% 1/10W
R012 1-216-304-11 METAL CHIP 3.3 5% 1/10W
R013 1-216-001-00 METAL CHIP 10 5% 1/10W
R014 1-216-295-00 METAL CHIP 0 5% 1/10W
R015 1-216-295-00 METAL CHIP 0 5% 1/10W
R016 1-216-033-00 METAL CHIP 220 5% 1/10W
< VIBRATOR >
X001 1-767-897-12 VIBRATOR, CRYSTAL 24.576MHz
MISCELLANEOUS
*************
1-757-665-11 CORD, POWER (EXCEPT EZ111/
EZ212/EZ414/EZ715/EZ717)
1-777-855-51 CORD, POWER
(EZ111/EZ212/EZ414/EZ715/EZ717)
1-757-690-11 FLAT CABLE FMD-022
(EXCEPT EZ115/ED215/ED313/EZ111/EZ212)
1-757-691-11 FLAT CABLE FMD-023
(ED115/ED215/ED313/EZ111/EZ212)
1-757-551-11 FLAT CABLE FAC-009
MA-402 NK-11
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
