Sony SS-CEP50 - Front Panel Section; MAIN Board

HCD-EP50
8
3-3. MAIN BOARD
Note: Follow the disassembly procedure in the numerical order given.
3-2. FRONT PANEL SECTION
6 connector
(CN3)
3 two screws
(+K3
× 5)
1 two screws
(BTP2.6
× 10)
2 two screws
(BVTP3
× 10
)
3 two screws
(+K3
× 5)
3 two screws
(+K3
× 5)
7 connector
(CN601)
8 connector
(SW300)
9 front panel section
5
4 claw
6 connector
(CN14)
6 connector
(CN15)
5 connector
(CN5)
4 connector
(CN201)
3 connector
(CN7)
2 connecto
r
(CN11)
1 connector
(CN9)
1 connector
(CN4)
9 MAIN board
7 screw
(+BTP2.6
× 8)
8
