Sony SS-CEP50 - Printed Wiring Board - POWER Board

HCD-EP50
2626
POWER BOARD
AC IN
L601
RE601
(US, CND, MX)
E C B
B C E
CN601
18
T602
POWER
TRANSFORMER
(SUB)
T601
POWER
TRANSFORMER
(MAIN)
E
MAIN BOARD
CN1
3
4
2
1
12 3 4
A
B
C
D
E
F
G
1 2 3 4 5 6 7 8
6-13. PRINTED WIRING BOARD – POWER Board –
(Page 23)
• Semiconductor
Location
Ref. No. Location
D601 B-8
D602 B-8
D603 C-8
D604 C-8
D605 B-6
D606 B-6
D607 C-6
D608 C-6
D612 F-6
D613 F-6
D615 D-5
D616 E-5
D617 E-5
D618 D-5
D621 D-5
Q605 E-7
Q606 E-7
Z601 F-7
