37
HCD-EP50
DISPLAY
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4727-038-A DISPLAY BOARD, COMPLETE (AEP, UK)
A-4727-280-A DISPLAY BOARD, COMPLETE
(AR, CND, MX, US)
A-4727-283-A DISPLAY BOARD, COMPLETE (HK, SP)
A-4727-597-A DISPLAY BOARD, COMPLETE (CH)
************************
4-235-973-01 LCD REFLECTOR
4-236-918-01 EM5 LED & REMOTE SENSOR HOLDER
4-236-919-01 EM5 REC. KNOB LED HOLDER
7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
< CAPACITOR >
C301 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C302 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C303 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C304 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C305 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C306 1-102-962-00 CERAMIC 30PF 5% 50V
C307 1-102-962-00 CERAMIC 30PF 5% 50V
C308 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C309 1-126-514-11 ELECT 22uF 20% 10V
C310 1-164-159-11 CERAMIC 0.1uF 50V
C311 1-164-159-11 CERAMIC 0.1uF 50V
C312 1-126-382-11 ELECT 100uF 20% 10V
C313 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C315 1-115-872-11 ELECT 2.2uF 20% 50V
(AEP, UK)
C316 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C317 1-126-382-11 ELECT 100uF 20% 10V
(AEP, UK)
C318 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(AEP, UK)
C319 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(AEP, UK)
C320 1-126-382-11 ELECT 100uF 20% 10V
(AEP, UK)
C321 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(AEP, UK)
C322 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(AEP, UK)
C323 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(AEP, UK)
C324 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C325 1-126-382-11 ELECT 100uF 20% 10V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C326 1-126-382-11 ELECT 100uF 20% 10V
C327 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C328 1-164-159-11 CERAMIC 0.1uF 50V
< LIQUID CRYSTAL DISPLAY >
CN301 1-804-496-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77 (EXCEPT AEP, CH, UK)
D305 8-719-991-33 DIODE 1SS133T-77
D306 8-719-991-33 DIODE 1SS133T-77
D307 8-719-991-33 DIODE 1SS133T-77
D308 8-719-991-33 DIODE 1SS133T-77
D309 8-719-991-33 DIODE 1SS133T-77
D310 8-719-991-33 DIODE 1SS133T-77
D311 8-719-991-33 DIODE 1SS133T-77 (AEP, UK)
D312 8-719-062-11 LED SEL2215S-CD (TIMER)
D313 8-719-062-11 LED SEL2215S-CD (z)
D315 8-719-991-33 DIODE 1SS133T-77
D316 8-719-991-33 DIODE 1SS133T-77
D317 8-719-991-33 DIODE 1SS133T-77
D318 8-719-991-33 DIODE 1SS133T-77 (AEP, UK)
D701 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D702 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D703 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D704 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D705 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D706 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D707 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D708 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
D709 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT)
< IC >
IC301 6-800-711-01 IC uPD78064GF-187-3BA
IC302 8-759-251-04 IC AT24C02-10PC
IC304 8-759-971-11 IC PST529D
IC305 8-759-557-36 IC BU1924F-E2 (AEP, UK)
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AR : Argentina model
CH : Chinese model
CND : Canadian model
HK : Hong Kong model
MX : Mexican model
SP : Singapore model
Ver 1.1
